DWB100CE20-3DX

The DWB100CE20-3DX has an interrupting rating of 10kA at 480Y/277VAC and 25kA at 240VAC.

It features a fixed thermal and fixed magnetic trip unit for consistent overcurrent protection.

Yes, it is UL489 listed, meeting safety and performance standards for industrial use.

The magnetic trip point is 1000A for the DWB100CE20-3DX.

It is designed for protecting feeders, branch circuits, and critical machinery in industrial systems.

WEG products meet extensive international standards across multiple critical categories, including safety, electromagnetic compatibility (EMC), functional safety, and regulatory compliance. Key certifications include UL, cUL, CE, TÜV Rheinland, and compliance with international standards such as EN 61800 series, IEC 61508, ISO 13849-1, and directives like Low Voltage (2014/35/EU), EMC (2014/30/EU), and RoHS. Their products are certified for safe operation in various industrial environments, with specific standards covering electrical safety, thermal performance, electromagnetic immunity, and environmental protection.

WEG offers an 18-month standard warranty for automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Repairs must be performed by authorized WEG service, and the warranty is limited to the replacement or repair of the product itself, excluding consequential damages. Extended warranty options are available, including purchasing additional coverage at 2.5% of the product's selling price per year, up to 4 additional years.

WEG products are extensively used across multiple industrial sectors, including packaging equipment, material handling, food processing, pumps, medical/lab equipment, door/gate openers, office machinery, and lawn/garden applications. Their versatile DC motors and variable frequency drives (VFDs) are designed for general industrial use, with solutions ranging from off-the-shelf products to custom OEM designs that meet UL/CSA standards for diverse manufacturing and processing environments.

WEG offers comprehensive technical support through multiple channels, including a dedicated Automation Service Department accessible via toll-free phone (1-877-934-3748) and email ([email protected]). They maintain a global network of accredited service centers worldwide, which customers can locate on their website. Additionally, WEG provides warranty support and technical assistance for their industrial automation products, with pre-approval required for warranty repairs.

WEG products feature advanced industrial automation technologies with key characteristics including high performance, flexibility, and connectivity. Their flagship CFW900 Variable Speed Drive demonstrates core product strengths: intelligent thermal management, built-in safety functions, IoT readiness, advanced energy saving capabilities, and comprehensive communication protocols. WEG drives offer robust performance with features like 150% overload capacity, modern graphic HMI, plug-and-play expansion modules, and compatibility across multiple industrial segments including food and beverage, pulp and paper, and manufacturing.

WEG products support multiple industrial communication protocols across their product lines, including EtherNet/IP, Modbus-TCP, Modbus-RTU, CANopen, and optional protocols like Profibus-DP and DeviceNet. Specifically, the PLC500 offers 2x Gigabit Ethernet Ports, 1x CAN Port, and 1x RS485 port, enabling seamless integration with major industrial communication networks.

WEG products feature multiple environmental ratings and protection classes. They offer Protection Class 3C2 as a standard coating and Protection Class 3C3 as an optional extra coating, both compliant with IEC 60721-3-3. Environmental specifications include air relative humidity from 5% to 95% non-condensing, altitude ratings up to 1,000m standard (with current derating above that), and Pollution Degree 2 classification with non-conductive pollution requirements.

WEG offers a comprehensive range of accessories across multiple product lines. For variable frequency drives like the CFW900, accessories include I/O expansion modules, communication modules, encoder modules, temperature transducer modules, relay output modules, and HMI accessories. These accessories expand communication capabilities, input/output functions, and application flexibility. Most accessories are interchangeable between drive frames and can be installed in backplane slots, with communication network accessories limited to one per variable speed drive.

WEG offers a comprehensive range of industrial automation products, including variable frequency drives (CFW series like CFW100, CFW300, CFW500), soft starters (SSW series including SSW05, SSW07, SSW900), and the innovative Motion Fleet Management (MFM) system for predictive maintenance and asset monitoring. Their product lines are designed to support industrial automation needs across various sectors, providing solutions for motor control, fleet management, and operational efficiency.

WEG products are typically installed with careful attention to mounting specifications, protection ratings, and airflow requirements. For variable speed drives like the CFW900, installation methods include surface mounting, flange mounting, and side-by-side configurations with specific clearance guidelines. Installers must follow precise dimensional requirements for each product frame size, ensuring proper ventilation and electrical connections.
