Overview
- 8-digit LCD display with 9mm high-contrast characters
- Dual-mode input: 10-110VDC or 10-240VAC
- Four timing modes: up/down with direction indication
- 10-year battery life and IP65/NEMA 4X environmental protection
- External reset input and integral backlight (5VDC supply required)
Specifications
Connection Type | Screw Terminals |
IP Rating | IP65 |
Mounting Type | Panel Mount |
Mounting Type | Front panel |
Nema Rating | NEMA 4X |
Series | 7511 |
Series | 7511HV |
Size | 1/32 DIN |
Voltage Rating | 10-240 VAC / 10-110 VDC |
Voltage Rating | 10-110VDC/10-240VAC |
Frequently Asked Questions
What is the expected battery life of the 7511 series timer?
The 7511 series timer has an expected battery life of 10 years, utilizing the latest CMOS circuitry.
What input voltages does the 7511HV model accept?
The 7511HV model permits triggering from any voltage between 10-240VAC or 5-110VDC, with a ±10% tolerance.
What are the display specifications for the 7511 series timer?
The timer features an 8-digit black LCD display with 9mm high characters and leading zero blanking.
What is the operating temperature range for the 7511 series timer?
The timer operates within a temperature range of -10°C to +60°C (14°F to 140°F).
Does the 7511 series timer have backlighting?
Yes, the timer has backlighting, but it requires an external 5VDC power supply.
What are the dimensions for the panel cutout?
The panel cutout required for the 7511 series timer is 45mm x 22.5mm.
What is the minimum contact closure time for the timer?
The minimum contact closure time required for the timer is 1 second.
What is the accuracy of the 7511 series timer?
The timer has an accuracy of +/-0.002% at 25 degrees C.
How many timing modes does the 7511 series timer support?
The 7511 series timer supports four different timing modes and can time up or down.
Can the 7511 series timer be reset externally?
Yes, the timer features an external reset input for convenient resetting.
