TE Connectivity TCD14741111-001 - M12 to RJ45 Cable Assembly, 4 Position, .5 m, Industrial Ethernet, Ethernet, D Code, M12 Plug End A, RJ45 Plug End B, Shielded, Double Ended
TE Connectivity

TCD14741111-001

Documents & Media
Full Engineering Drawing

Contact for Pricing

Minimum Qty: 5

Multiplier: 200

*Contact for lower quantities*

Overview

TE Connectivity TCD14741111-001 is a shielded M12 to RJ45 cable assembly designed for industrial Ethernet applications. This 0.5-meter, 4-position cable features a D Code M12 plug (End A) and RJ45 plug (End B) for direct connectivity between industrial and standard Ethernet devices. The shielded construction minimizes electromagnetic interference, ensuring stable data transmission in demanding environments like automation, robotics, and industrial networking. Compatible with industrial Ethernet protocols, this cable assembly supports reliable high-speed data transfer in harsh conditions. The robust design meets industrial standards for durability and performance, making it ideal for factory automation, process control, and machine-to-machine communication. With a US-made construction and TE Connectivity’s reputation for quality connectivity solutions, this cable assembly delivers consistent, interference-free performance in critical applications.
  • 0.5-meter length for flexible installation in tight spaces
  • 4-position configuration with shielded design for EMI protection
  • D Code M12 plug (End A) and RJ45 plug (End B) for direct device connectivity
  • Rugged construction for harsh industrial environments
  • Compatible with industrial Ethernet protocols for reliable data transmission

Specifications

Application
Industrial
Color
Black
Connection Type
M12 Plug (D Code) to RJ45 Plug
Connection Type
M12 Plug to RJ45 Plug
Insulation Material
Nylon
Jacket Material
PVC
Length
0.5 m
Material
PA66+25GF
Poles
4
Size
0.5 M
Size
M12 to RJ45
Type
M12 to RJ45
Voltage Rating
30 V
