TE Connectivity 3-1423008-5 - General Purpose Power Relay, DC, Monostable, 2 Form C DPDT-CO, 30 A Contact Rating, 12 VDC Coil Voltage, Potter & Brumfield T92. P&B T92 Series two-pole 30A Panel Mount or PCB Power Relay. 40-amp relays feature 2 form A (NO) and 2 form C (CO) switching capability. Designed to control compressor loads to 3.5 tons, 110LRA / 25.3FLA.
TE Connectivity

3-1423008-5

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 120

Multiplier: 120

*Contact for lower quantities*

Overview

The TE Connectivity Potter & Brumfield T92 Series power relay (SKU: 3-1423008-5) is a robust, general-purpose relay designed for demanding power switching applications. Featuring a 12 VDC coil voltage and a substantial 30 A contact rating, this relay is engineered for reliability and performance. Its configuration includes 2 Form C (DPDT-CO) contacts, providing versatile switching capabilities for both normally open (NO) and normally closed (NC) circuits. This makes it ideal for controlling significant loads, such as compressor applications up to 3.5 tons, with a motor locked rotor amperage (LRA) of 110A and a full load amperage (FLA) of 25.3A. The T92 relay offers flexible mounting options, supporting both panel mount and PCB mounting, allowing for straightforward integration into various system designs. TE Connectivity's T92 series is recognized for its durable construction and consistent operation, making it a dependable choice for industrial control systems, HVAC equipment, and other applications requiring high current switching. Its monostable design ensures a clear switching state when the coil is energized or de-energized. This relay is a direct replacement for many standard 30A power relays and is built to meet the operational requirements of commercial and industrial equipment.
  • Manufacturer: TE Connectivity
  • Series: T92
  • Contact Rating: 30 A
  • Coil Voltage: 12 VDC
  • Contact Configuration: 2 Form C (DPDT-CO)

Specifications

Amperage Rating
30 A
Application
Industrial controls
Connection
Quick Connect Terminals
Depth
2.7 in
Depth
68.58 mm
Enclosure
Dust Protected
Height
1.0402 in
Height
26.42 mm
Mounting
Panel
Operating Temperature, Maximum
185 F
Operating Temperature, Maximum
85 C
Operating Temperature, Minimum
-67 F
Operating Temperature, Minimum
-55 C
Resistance
86
Special Features
UL Coil Insulation Class F
Type
General Purpose Power Relay
Width
1.3598 in
Width
34.54 mm
With LED Indication
NO
