TE Connectivity 1SNK922302R0000 JB22-2 2-POLE SCREW JUMPER BAR
Alternate Item Number: 1SNK922302R0000
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 2-pole screw jumper bar for industrial electrical connections
- Screw terminals for secure conductor attachment
- Designed for junction boxes and control panel setups
- Manufactured in Switzerland to professional electrical standards
- UNSPSC code 31161500 for electrical connectors and terminals
Specifications
Ambient Air Temperature | Operation -55 ... +110 °C |
ATEX Certificate | 1SND162004A1708 |
CB Certificate | 1SND161034A0202 |
Connection Type | Screw Terminal |
Current (Icw) | Rated Voltage (Ur): 1000 V |
Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20 |
Dielectric Test Voltage | 2200 V |
E-nummer | 2925393 |
ETIM 4 | EC000489 - Cross-connector for terminal block |
ETIM 5 | EC000489 - Cross-connector for terminal block |
ETIM 6 | EC000489 - Cross-connector for terminal block |
Function | Jumper Bars |
Insulation Material | Polyamide |
Object Classification Code | X |
Package Level 1 Depth / Length | 105 mm |
Package Level 1 EAN | 3472599000000 |
Package Level 1 Gross Weight | 0.135 kg |
Package Level 1 Height | 45 mm |
Package Level 1 Units | 5 piece |
Package Level 1 Width | 45 mm |
Package Level 2 Depth / Length | 300 mm |
Package Level 2 Gross Weight | 3.19 kg |
Package Level 2 Height | 200 mm |
Package Level 2 Units | 105 piece |
Package Level 2 Width | 200 mm |
Package Level 3 Units | 10080 piece |
Poles | 2 |
Power Loss | 6.1 W |
Product Net Depth / Length | 20.7 mm |
Product Net Height | 35 mm |
Product Net Length | 20.7 mm |
Product Net Width | 22 mm |
Product Packing Type | Box |
Rated Current (In) | Main Circuit 192 A |
Recommended Screw Driver | 4 mm |
RoHS Information | 1SND230499F0202 |
RoHS Status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
Series | JB22 |
Spacing | 22 mm |
Suitable For | D70/22 |
UL/CSA | Environmental |
Frequently Asked Questions
What is the rated current for the JB22-2 jumper bar?
The rated current for the main circuit of the JB22-2 jumper bar is 192 A.
What is the maximum operating voltage for the JB22-2 jumper bar?
The rated voltage for the JB22-2 jumper bar is 1000 V, and the maximum operating voltage under UL/CSA is 600 V.
What is the ambient temperature range for operation and storage?
The ambient air temperature for both operation and storage is -55 to +110 °C.
What is the IP rating for the main terminals of the JB22-2 jumper bar?
The main terminals have a degree of protection of IP20 according to IEC 60529, IEC 60947-1, and EN 60529.
What is the insulation material used in the JB22-2 jumper bar?
The insulation material used in the JB22-2 jumper bar is Polyamide.
What is the recommended screwdriver size for the JB22-2 jumper bar?
The recommended screwdriver size for the JB22-2 jumper bar is 4 mm.
What are the dimensions of the JB22-2 jumper bar?
The product dimensions are: Width 22 mm, Height 35 mm, and Depth/Length 20.7 mm.
What is the weight of a single JB22-2 jumper bar?
The product net weight of a single JB22-2 jumper bar is 27 g.
What is the rated impulse withstand voltage for the JB22-2 jumper bar?
The rated impulse withstand voltage for the JB22-2 jumper bar is 8000 V.
What is the dielectric test voltage for the JB22-2 jumper bar?
The dielectric test voltage for the JB22-2 jumper bar is 2200 V.
