TE Connectivity 1SNA519103R0200 - PC-RG2.5-2 RING LUG JUMPER-2 POLES

TE Connectivity 1SNA519103R0200 PC-RG2.5-2 RING LUG JUMPER-2 POLES

Alternate Item Number: 1SNA519103R0200


Documents & Media
BrochureFull Engineering DrawingSpecification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The TE Connectivity PC-RG2.5-2 is a two-pole ring lug jumper designed for reliable electrical connections in industrial settings. SKU 1SNA519103R0200, this jumper facilitates secure power and signal transmission. Its robust construction ensures stable and corrosion-resistant connections, making it suitable for control panels, power distribution, and industrial machinery. Manufactured by TE Connectivity, this component adheres to high industry standards for performance and durability. Its specific application is within electrical connection systems requiring a two-pole jumper.
  • Two-pole ring lug jumper for industrial connections
  • Facilitates secure power and signal transmission
  • Robust construction for stable connections
  • Corrosion-resistant design
  • Manufactured by TE Connectivity

Specifications

Ambient Air Temperature
Operation -40 ... +100 °C
Color
Orange
Connection Type
Ring Lug
Declaration of Conformity - CE
1SND225158C1001
ETIM 4
EC000489 - Cross-connector for terminal block
ETIM 5
EC000489 - Cross-connector for terminal block
ETIM 6
EC000489 - Cross-connector for terminal block
Function
Jumper Bars
Insulation Material
Polyamide
Package Level 1 Depth / Length
31 mm
Package Level 1 EAN
3472600000000
Package Level 1 Gross Weight
0.1 kg
Package Level 1 Height
65 mm
Package Level 1 Units
25 piece
Package Level 1 Width
55 mm
Poles
2
Power Loss
0.8 W
Product Net Depth / Length
25.8 mm
Product Net Height
14.1 mm
Product Net Width
3.1 mm
Product Packing Type
Box
Rated Current (In)
Main Circuit 24 A
Rated Voltage (Ur)
800 V
RoHS Information
1SND230547F0201
RoHS Status
Following EU Directive 2011/65/EU
Series
PC-RG2.5-2
Series
PC-RG2.5
Size
RG2.5
Spacing
9 mm
Suitable For
RGW2.5
UL/CSA
Flammability According to UL94: V0
Control Transformer Accessories - Optional Unfused Finger Guard Kits, 50 VA, For AJ, AR, MQMJ, MEMX, QR, SP, PG, PP Suffixes

FG1

Control Transformer Accessories - Optional Unfused Finger Guard Kits, 50 VA, For AJ, AR, MQMJ, MEMX, QR, SP, PG, PP Suffixes
Double lever locking base with posts and access cover, 16 contacts with ground connection, NPT entry - 1 Inch x 3/4 Inch.

BB216MV

Double lever locking base with posts and access cover, 16 contacts with ground connection, NPT entry - 1 Inch x 3/4 Inch.
Self-Sticking Polyester Safety Labels, Polyester 7 x 5, Legend WARNING Arc Flash Hazard, Black on Orange

LB94914

Self-Sticking Polyester Safety Labels, Polyester 7 x 5, Legend WARNING Arc Flash Hazard, Black on Orange
Buried Utility Tape, Red, Legend HIGH VOLTAGE LINE, 3 inch width, 1000 Feet

NA-0606

Buried Utility Tape, Red, Legend HIGH VOLTAGE LINE, 3 inch width, 1000 Feet
SMS Series Vinyl Sleeve Marker - Closed Spring-Action, Recommended Wire Diameter .059 - .197 inches, Wire Range 16-10AWG, Color White, Legend -, Packaging Bag

SMS196-9-DH

SMS Series Vinyl Sleeve Marker - Closed Spring-Action, Recommended Wire Diameter .059 - .197 inches, Wire Range 16-10AWG, Color White, Legend -, Packaging Bag
SMC Series Vinyl Sleeve Clip On Marker - Open Clip-On, Recommended Wire Diameter 0.094 -.118 inches, Wire Range 18-16AWG, Color White, Legend 7, Packaging Strips

SMC118-9-7

SMC Series Vinyl Sleeve Clip On Marker - Open Clip-On, Recommended Wire Diameter 0.094 -.118 inches, Wire Range 18-16AWG, Color White, Legend 7, Packaging Strips
O Type Vinyl Sleeve Markers - Color White, Legend Z, Wire Range 10-6

SMO256-9-Z

O Type Vinyl Sleeve Markers - Color White, Legend Z, Wire Range 10-6
SMC Series Vinyl Sleeve Clip On Marker - Open Clip-On, Recommended Wire Diameter .197 - .244 inches, Wire Range 8-6AWG, Color Yellow, Legend -, Packaging Strips

SMC244-4-DH

SMC Series Vinyl Sleeve Clip On Marker - Open Clip-On, Recommended Wire Diameter .197 - .244 inches, Wire Range 8-6AWG, Color Yellow, Legend -, Packaging Strips

Frequently Asked Questions

What is the primary benefit of RGW Ring Lug Terminal Blocks?

RGW terminal blocks offer fast and secured wiring for ring lugs, with captive nuts in pivoting wings for convenient connection.

What is the rated voltage for RGW2.5 terminal blocks?

The rated voltage for RGW2.5 terminal blocks is 800 V according to IEC standards and 600 V for UL and CSA.

Are RGW terminal blocks suitable for railway applications?

Yes, RGW terminal blocks comply with IEC 61373 for shock and vibration and EN 45545-2 for fire protection (HL3 R22).

What is the rated current for RGW6 terminal blocks?

RGW6 terminal blocks have a rated current of 41 A (IEC), 30 A (UL), and 30 A (CSA).

What makes the RGW terminal block connection secure?

The connection is secured by a combination of stud, safety wings, captive nut, and ring lug, with self-locking wings to prevent opening.

What is the maximum conductor size for RGW2.5 terminal blocks?

RGW2.5 terminal blocks support a rated cross-section of 2.5 mm² (14 AWG) for rigid and flexible conductors.

What is the maximum conductor size for RGW6 terminal blocks?

RGW6 terminal blocks support a rated cross-section of 6 mm² (10 AWG) for rigid and flexible conductors.

What test plugs are compatible with RGW2.5-T terminal blocks?

RGW2.5-T terminal blocks have test sockets compatible with DIA 2 mm (0.079 in) test plugs.

How much faster are RGW terminal blocks compared to open style?

RGW terminal blocks are up to 45% faster than open style terminal blocks due to captive and ready-to-tighten nuts.

What is the torque specification for RGW2.5 terminal block nuts?

The recommended torque for RGW2.5 terminal block nuts is 0.6 to 0.8 N.m (5.3 to 7.1 lb.in).
