TE Connectivity
1SNA165575R2500
Alternate Item Number: 016557525
Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- Terminal block for industrial electrical connections
- Secure wiring in control panels and automation equipment
- Made by TE Connectivity
- Compact design
- Significant current capacity
Specifications
Amperage Rating | 125 A |
Amperage Rating | 125;125.0000 A;A |
Application | Ground + Neutral |
Color | Blue;Green-Yellow |
Connection Type | Screw Terminal |
Electrical Connection 1 | Screw clamp |
Electrical Connection 2 | Screw clamp |
Flammability | V0 |
Flammability - Metric | V0 |
Height | 1.9291 in |
Height | 48.9991 mm |
Height | 1.929134 in |
Height - Metric | 49 mm |
Length | 1.830709 in |
Length - Metric | 6.3 mm |
Material | Terminal Block |
Material | Polyamide |
Mounting | DIN Rail |
Series | M35 |
Size | M35/16 |
Spacing | 1.259843 in |
Spacing | 1.25984251968504;32 in;mm |
Temperature | -67 - 230 °F |
Temperature - Metric | -55 - 110 °C |
Type | M35/16.PE.N |
Voltage Rating | 800 V |
Width | 1.259843 in |
Width | 31.9989 mm |
Width | 1.2598 in |
Width - Metric | 32 mm |
Wire Size | 0.05424675 in² |
Wire Size | 35 mm² |
