Contact for Pricing
Minimum Qty: 120
Multiplier: 120
*Contact for lower quantities*
Overview
- TE Connectivity T92 Series General Purpose Power Relay
- 30 Amp Contact Rating at 240 VAC Coil Voltage
- 2 Form A (DPST-NO) Contact Configuration
- Suitable for Compressor Loads up to 3.5 Tons (110LRA / 25.3FLA)
- Panel Mount or PCB Mount Capability
Specifications
Amperage Rating | 30 A |
Application | Industrial controls |
Connection | Quick Connect Terminals |
Current Rating | 30 A |
Depth | 2.7 in |
Depth | 68.58 mm |
Enclosure | Flux Resistant Automatic Solder Capable |
Height | 1.0402 in |
Height | 26.42 mm |
Mounting | Panel |
Operating Temperature, Maximum | 149 F |
Operating Temperature, Maximum | 65 C |
Operating Temperature, Minimum | -67 F |
Operating Temperature, Minimum | -55 C |
Poles | 2 Form A DPST-NO |
Resistance | 3800 |
Series | T92 |
Special Features | UL Coil Insulation Class F |
Type | General Purpose Power Relay |
Voltage Rating | 240 Vac |
Width | 1.3598 in |
Width | 34.54 mm |
With LED Indication | NO |
