Contact for Pricing
Overview
- Nominal Output Voltage: 24VDC
- Nominal Output Current: 1.25A
- Max. Power: 30W
- Frequency Rating: 50/60Hz
- DIN Rail Mounting
Specifications
Amperage Rating | 1.25 A |
Application | ATM Machines;Heavy and Light Industrial Machinery;instrumentation;Scanners;Test and Measure Equipment;Vending Machines |
Application | Heavy and Light Industrial Machinery; Test and Measure Equipment; Scanners; instrumentation; ATM Machines; Vending Machines; |
Brand Name | SolaHD |
Cable Size | Input Connector size range: 22-12 AWG (0.4-3.4 mm2) for solid conductors;Output Connector size range: 20-12 AWG (0.5-3.4 mm2) for solid conductors |
Current Rating | 1.25 A |
Efficiency | 88 % typ |
Enclosure | To be installed in an enclosure |
Environmental Conditions | To be installed in a controlled environment |
Frequency | 50/60 Hz |
Frequency Rating | 50/60 HZ |
Frequency Rating, Maximum | 60 Hz |
Frequency Rating, Minimum | 50 Hz |
Fuse Rating | Internally Fused |
Height | 2.95 IN |
Length | 3.52 in |
Material | Plastic |
Mounting | DIN Rail |
Mounting Type | DIN Rail |
Phase | Single |
Phase | 1 |
Series | SVL Essential Din Rail Series |
Size | Compact |
Special Features | Universal Input; Convection cooling; DC OK LED; NEC Class 2 output; Protection: short circuit, over voltage, overload, over temperature; Two year warranty |
Special Features | Convection cooling;DC OK LED;NEC Class 2 output;Protection: short circuit, over voltage, overload, over temperature;Two year warranty;Universal Input |
Standard | CE: IEC/EN 60950-1 2nd edition CB Scheme, NEC Class 2;UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1;UL Recognized Component, ITE for US and Canada: UL 60950-1/CSA C22.2 60950-1 2nd edition |
Standard | UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1; UL Recognized Component, ITE for US and Canada: UL 60950-1/CSA C22.2 60950-1 2nd edition; CE: IEC/EN 60950-1 2nd edition CB Scheme, NEC Class 2 |
Sub Brand | Sola |
Type | SVL Essential Din Rail Series |
Voltage Rating | 24 VDC |
Wattage | 30 W |
Width | 0.82 in |
Package Dimensions (L x W x H) | 3.4 IN x 4.3 IN x 1.3 IN |
Package Dimensions (L x W x H) | 8.636 cm x 10.922 cm x 3.302 cm |
Package Weight (Imperial) | 0.300 L |
Package Weight (Metric) | 0.136 kg |
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
Frequently Asked Questions
How does short circuit protection work?
Short circuit protection operates in hiccup mode and is non-latching, with auto-recovery when the fault is removed.
What is the operating temperature range for SVL power supplies?
The operating temperature range for these power supplies is -20 °C to +70 °C.
What is the AC input voltage range for these power supplies?
The AC input voltage range is 85-264 Vac, with a nominal range of 100-240 Vac.
What safety certifications do SVL Series power supplies have?
All models are UL 508 Listed and UL 60950 Recognized. They also comply with EMC and Low Voltage Directives.
What is the warranty period for SVL Series power supplies?
SVL Series power supplies come with a two-year limited warranty.
What protection features do SVL Series power supplies include?
They include protection against short circuit, over voltage, overload, and over temperature.
What output voltages and power levels are available?
SVL Series power supplies offer 5, 12, 24, and 48 Volt combinations, ranging from 15 to 480 Watts.
How are SVL Series power supplies installed?
SVL Series power supplies feature DIN rail mounting capability for quicker and easier installation.
What are the available output voltage and power options?
SVL power supplies are available in 5, 12, 24, and 48 Volt combinations, with power ratings ranging from 15 to 480 Watts.
What is the relative humidity operating condition?
The power supplies can operate in relative humidity from 5 to 95% RH, non-condensing.
