Overview
- DIN rail mount for easy integration into industrial panels
- 120 VAC voltage rating for single-phase (L-N) systems
- Absorbs transient voltage spikes to protect sensitive electronics
- Compact design ideal for PLC enclosures, motor starters, and sensor arrays
- Manufactured by SolaHD in the US for reliable industrial power solutions
Specifications
Amperage Rating | 20 |
Application | Distribution Panels (<1200 A), Branch, Lighting and Control Panels, Factory Automation Installations, Dedicated Industrial Equipment |
Brand Name | SolaHD |
Connection | Parallel |
Connection Type | Screw Terminal |
Environmental Conditions | 0 to 95% non condensing PCT |
Frequency | 50/60 Hz |
Frequency Rating | 47 - 63 HZ |
Frequency Rating, Maximum | 63 Hz |
Frequency Rating, Minimum | 47 Hz |
Height | 3.2 |
Material | Metal Enclosure, NEMA 12 |
Mounting | Flange |
Mounting Type | DIN Rail |
Operating Temperature | -40 to 60 DEG C |
Operating Temperature, Maximum | 140 F |
Operating Temperature, Maximum | 60 C |
Operating Temperature, Minimum | -40 F |
Operating Temperature, Minimum | -40 C |
Phase | 3 Delta |
Phase | 3 |
Poles | 1P |
Response Time | <0.5 nsec |
Series | STV25K |
Size | 6.0 W x 4.0 D x 3.2 H |
Special Features | 100,000 amp peak current rating provides all mode protection against severe transients, Low clamping levels for more effective protection, 65 kAIC fault current fusing level provides safety and NEC conformance, LED status and audible alarms, Compact, rugged metal. |
Standard | cULus Listed: UL 1449, 3rd Edition, type 2 locations, UL Listed: NEMA type 12 enclosure, CSA Listed: CSA C22.2 No. 8, CSA TI I-IIB, TI A-24, RoHS Compliant |
Type | STV 100 K Series Surge Protection Devices |
Type Of Indicators | Red & Green LED, Audible Alarm |
Voltage Rating | 120 VAC |
Voltage Rating | 480 V |
Package Dimensions (L x W x H) | 8.2 IN x 6.3 IN x 2.7 IN |
Package Dimensions (L x W x H) | 20.828 cm x 16.002 cm x 6.858 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the input voltage for STV25K10S?
The STV25K10S operates on 120 Vac, single phase, with a range of 0-135 Vrms.
What is the surge protection capability?
These devices provide 25,000 Amps of surge protection per phase.
What is the maximum continuous operating voltage (MCOV)?
The Maximum Continuous Operating Voltage (MCOV) for the STV25K10S is 150 Vrms.
What is the operating temperature range?
The operating temperature range is -40 °C to +60 °C (-40 °F to +140 °F).
What is the maximum input current rating?
The input current rating for the device is 20 Amps.
What is the warranty period for this product?
The STV25K DIN Rail series comes with a standard ten year product warranty.
What is the primary function of the STV25K Series?
The STV25K Series provides point-of-use protection against damaging transients for dedicated equipment.
How is the STV25K mounted and connected?
It is DIN Rail mounted with screw terminals for #12 AWG. A chassis mount bracket is optional.
What modes of protection does it offer?
It offers all mode protection, including L-N, L-L, L-G, and N-G.
What is the response time of the surge protector?
The response time of the surge protective device is less than 0.5 nanoseconds.
