SDN5-24-480C

The SDN5-24-480C requires a nominal AC voltage of 380-480 Vac (range 320-540 Vac), 3-phase, or a nominal DC voltage of 600 Vdc (+/- 50 Vdc). It operates at 50/60 Hz.

The nominal output voltage is 24 Vdc, adjustable from 23.5 to 28.5 Vdc. The initial voltage setting is 24.5 V ± 1%.

The device operates at full power from -40°C to +60°C, with linear derating to 75% power up to 70°C. Storage temperature is -40°C to +85°C.

Yes, the SDN5-24-480C supports single or parallel operation, selectable via a front switch. For redundant operation, an external Redundancy module is required.

The power supply can be easily snap-on mounted to DIN TS35/7.5 or TS35/15 rail systems. Optional Panel Mount Adapter Brackets are available for screw mounting to a panel.

For input, use 16-10 AWG solid conductors with a screw torque of 4.4 lb-in (~50 N-cm). For output, use 16-10 AWG solid conductors with a screw torque of 7 lb-inch (~80 N-cm).

The unit features three visual status LEDs (Input, Output, Alarm) and a DC OK relay with a N.O. contact rated 200mA/50 Vdc, active when Vout > 18.5 Vdc +/-5%.

The SolaHD SDN5-24-480C comes with a 5-year limited warranty.

The SDN5-24-480C has an IP20 ingress protection rating, meaning it is touch-proof and protected against solid objects larger than 12.5 mm.

For proper convection cooling, 0.98 inches (25 mm) of free space is required above and below the unit, 0.98 inches (25 mm) on the left and right, and 0.59 inches (15 mm) in front.
