SDN5-24-100C

The nominal AC input voltage range is 100-240 Vac (85-264 Vac), and the nominal DC input voltage range is 100-340 Vdc (90-375 Vdc). The frequency range is 43-67 Hz.

The nominal output voltage is 24 Vdc, adjustable from 23.5-28.5 Vdc. The nominal current is 5 A (120 W) at +60°C.

The SolaHD SDN-C power supply comes with a 5-year limited warranty.

Yes, it has extensive international hazardous location certifications, including Class I, Zone 2, ATEX, IECEx, and ExEAC with a T4 rating.

The operating temperature range is -40°C to +60°C at full power. It can operate up to 70°C with linear derating to 75% power.

The power supply can be easily mounted by snapping onto a DIN TS35/7.5 or TS35/15 rail system. Optional panel mount adapter brackets are also available.

Yes, single or parallel operation is selectable via a front switch. For redundant operation, an external Redundancy module is required.

The unit features three visual LEDs for Input, Output, and Alarm status. A DC OK relay also provides diagnostic information to a PLC or controller.

Input and output connections require 16-10 AWG (1.5-6 mm2) solid or stranded conductors. Screw torque for these connections is 4.4-6.5 lb-inch.

Required free space is 0.98 in (25 mm) above and below, 0.39 in (10 mm) left and right, and 0.59 in (15 mm) in front.

SolaHD power supplies are UL 508 Listed for Industrial Control Equipment and comply with multiple international standards, including UL 60950, CUL/CSA-C22.2 No. 234-M90, and IECEx certifications. Our products meet EMC and Low Voltage Directives, with extensive hazardous location certifications including Class I Zone 2, ATEX, and IECEx, ensuring reliable performance in industrial environments.
