SolaHD
IE-120
UPC: 633914074296
Contact for Pricing
Overview
- Voltage rating: 120V AC
- Continuous current rating: 20A
- Active tracking technology for dynamic voltage regulation
- Industrial-grade components for harsh environments
- Compact design compliant with IEC 60384-7
Specifications
Amperage Rating | 10 AMPS |
Application | Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. |
Brand Name | SolaHD |
Class | Category A Ringwave (6kv, 200 A, 100 kHz) |
Connection | IEC 998 approved terminals |
Current Rating | 20 A |
Environmental Conditions | Humidity: 0 to 95% |
Frequency Rating | 47-63 HZ |
Frequency Rating, Maximum | 63 Hz |
Frequency Rating, Minimum | 47 Hz |
Height | 3.83 in |
Mounting | DIN/Flange |
Operating Temperature | -40 DEG C to +45 DEG C at Full Load; Derate Linearly to 60% at +70 DEG C |
Operating Temperature, Maximum | 45;70 C;C |
Operating Temperature, Minimum | -40 F |
Operating Temperature, Minimum | -40 C |
Phase | 1 |
Phase | Single |
Response Time | Normal Mode <0.5ns; Common Mode <5ns |
Response Time | Common Mode <5ns;Normal Mode <0.5ns |
Series | Islatrol IE Series |
Short Circuit Rating | Surge current capacity -- 45 |
Short Circuit Rating | Surge current capacity -- 45,000 Amps |
Short-Circuit Rating | Surge current capacity -- 45 |
Size | 4.06 Length x 3.06 Width x 3.83 High IN |
Special Features | Surge current capacity - 45,000 Amps; Transient protection in all modes: line to neutral, line to ground, and neutral to ground; LED status indication and form C contact for remote indication; DIN mountable enclosure |
Special Features | DIN mountable enclosure;LED status indication and form C contact for remote indication;Surge current capacity - 45,000 Amps;Transient protection in all modes: line to neutral, line to ground, and neutral to ground |
Standard | ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS |
Sub Brand | Edco |
Type | Surge Protective Devices |
Type Of Indicators | LED Power Indicators |
Voltage Rating | 120 V |
Voltage Rating | 120 Volts |
Package Dimensions (L x W x H) | 7.3 IN x 6.2 IN x 3.4 IN |
Package Dimensions (L x W x H) | 18.542 cm x 15.748 cm x 8.636 cm |
Package Weight (Imperial) | 1.400 L |
Package Weight (Metric) | 0.635 kg |
