Socomec 67230400 - Knife-edge fuse without striker aM type NH S2 500Vac 400A
Socomec

67230400

Contact for Pricing

Minimum Qty: 3

Multiplier: 3

*Contact for lower quantities*

Overview

The Socomec 67230400 NH S2 aM fuse is a knife-edge fuse designed for low-voltage electrical circuits up to 500V AC. Rated at 400A, this fuse provides reliable overcurrent protection in industrial applications where high breaking capacity and precision are required. The NH S2 size ensures compatibility with standard NH fuse holders, while the aM type designation indicates suitability for motor circuit protection and general industrial use. The knife-edge design allows for secure mounting in fuse bases, and the absence of a striker simplifies installation in confined spaces. This fuse is manufactured by Socomec, a trusted name in industrial electrical protection, and meets stringent safety and performance standards. Ideal for protecting transformers, motors, and distribution panels in manufacturing, energy, and infrastructure sectors.
  • Rated 400A for high-current industrial circuits
  • 500V AC voltage rating for low-voltage applications
  • NH S2 size compatible with standard NH fuse holders
  • aM type for motor circuit protection and general industrial use
  • Knife-edge design for secure mounting, no striker for confined spaces

Specifications

Connection Type
Knife-edge
Current Rating
400A
Current Rating
400 A
Mounting Type
knife-edge
Mounting Type
knife-edge fuse base
Series
NH S2
Series
NH S2 aM
Size
NH S2
Voltage Rating
500 VAC
Voltage Rating
500VAC
Voltage Rating
500V AC
Package Dimensions (L x W x H)
0.5412 FT x 0.2624 FT x 0.5412 FT
Package Dimensions (L x W x H)
0.165 m x 0.08 m x 0.165 m
Package Weight (Imperial)
1.368 L
Package Weight (Metric)
0.622 kg
