Overview
The Schlegel Elektrokontakt SSSA14 is a maintained key actuator designed for industrial control applications. This unit features a 1 NC + 1 NO contact configuration and utilizes a 4-pole M12 connector for connection. Built to EN 60947-5-1 and EN 61058-1 standards, it offers reliable operation. The actuator is IP65 rated, ensuring protection against dust and water ingress. It is supplied with two keys, with other lock types available upon request. The contact material is AgNi, and the front bezel is silver-coloured. This maintained key switch holds its position until manually reset, making it suitable for applications requiring sustained control states. Manufactured in Germany.
- Maintained key actuator with 1 NC + 1 NO contact configuration
- IP65 rated for dust and water ingress protection
- 4-pole M12 connector (A coded) for secure connection
- Compliant with EN 60947-5-1 and EN 61058-1 standards
- Supplied with two keys; other lock types available on request
Specifications
Bezel Color | Silver |
Certifications | CCC, CE, cURus, DNV, ENEC10, VDE, UKCA |
Color | Silver |
Connection Type | 4-pole M12 connector |
IP Rating | IP65 |
Material | AgNi |
Mechanical Life | 30.000 operations |
Mounting Position | any |
Panel Cutout | Ø 22.3 mm |
Panel Thickness | 1.5 mm to 8 mm |
Poles | 2 (1 NC + 1 NO) |
Product Type | Schlüsselschalter |
Series | RONDEX |
Shape | Round |
Storage Temperature | -40 °C to 80 °C |
Switching Function | Rastfunktion |
Switching Positions | 0S / 90R |
Temperature Rating | -25 °C to 70 °C |
