Schlegel Elektrokontakt RRJVAWC Switching Function: Momentary / MaintainedPanel Cutout: � 22.3 mm Direction-Angle: 1 x…
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
The Schlegel Elektrokontakt RRJVAWC (SKU: RRJVAWC) is a versatile industrial switch designed for precise control applications. It offers both momentary and maintained switching functions, providing flexibility for various operational needs. The switch features a standard 22.3 mm round panel cutout, ensuring compatibility with common industrial enclosures. Users can select from two directional angles: 40 degrees or 90 degrees, allowing for tailored actuator positioning. Constructed with a polished stainless steel bezel, the RRJVAWC delivers a durable and professional aesthetic suitable for control panels and machinery. Its Protection Class II rating signifies protective insulation, enhancing operational safety. This switch is an ideal component for industrial automation systems, machine controls, and any application requiring reliable and configurable switching. Manufactured in Germany (DE), the RRJVAWC meets stringent quality standards for dependable performance in demanding environments.
- Momentary and Maintained Switching Functions
- 22.3 mm Round Panel Cutout
- Selectable 40° or 90° Directional Angles
- Polished Stainless Steel Bezel
- Protection Class II (Protective Insulation)
Specifications
Bezel Color | Stainless steel |
Color | Stainless Steel |
Illumination | No |
Panel Cutout | Ø 22.3 mm |
Product Type | Wahltaste |
Series | RONTRON-R-JUWEL |
Size | 22.3 mm |
Switching Function | Tast- und Rastfunktion |
Switching Positions | 90R / 0R / 40T |
RRJWB
Switching Function: Maintained Direction-Angle: 2 x 60� DegreesPanel Cutout: � 22.3 mm Shape: RoundIllumination: No Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Silver
RRJWCL_GB
Switching Function: Momentary / MaintainedPanel Cutout: � 22.3 mm Direction-Angle: 1 x 40� Degrees / 1 x 90� Degrees RoundIllumination: Yes Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Silver Color LED: Yellow
RRJWBLSW_GB
Switching Function: Maintained Direction-Angle: 2 x 60� DegreesPanel Cutout: � 22.3 mm Shape: RoundIllumination: Yes Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Black Color LED: Yellow
RRJVAWCL_BL
Switching Function: Momentary / Maintained Direction-Angle: 1 x 40� Degrees / 1 x 90� DegreesPanel Cutout: � 22.3 mm Shape: RoundIllumination: Yes Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Stainless Steel Polished Color LED: Blue
RRJVAWCL_KL
Switching Function: Momentary / Maintained Direction-Angle: 1 x 40� Degrees / 1 x 90� DegreesPanel Cutout: � 22.3 mm Shape: RoundIllumination: Yes Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Stainless Steel Polished Color LED: White
RRJVAWCL_RT
Switching Function: Momentary / Maintained Direction-Angle: 1 x 40� Degrees / 1 x 90� DegreesPanel Cutout: � 22.3 mm Shape: RoundIllumination: Yes Labeling Option: NoProtection Class: II (protective insulation) Bezel Color: Stainless Steel Polished Color LED: RedFrequently Asked Questions
What is the protection rating of the RRJVAWC?
The RRJVAWC has an IP65 protection rating.
What is the required installation opening size?
The required installation opening is a diameter of 22.3 mm.
Does the RRJVAWC have illumination?
No, the RRJVAWC does not have illumination.
What is the front frame color of the RRJVAWC?
The front frame color is shiny stainless steel.
What are the switching functions available?
It offers both momentary and latching switching functions.
What are the specific switching positions?
It has a latching position at -90°, a zero position at 0°, and a momentary position at 40°.
