Pfannenberg
46714000125
Alternate Item Number: COND. 37KW 9000MC-134PA-R407C
Contact for Pricing
Overview
The Pfannenberg 9000MC-134PA-R407C (SKU: 46714000125) is a 37kW air-cooled condenser designed for industrial refrigeration and HVAC systems. This unit uses R407C refrigerant and operates on 400/460V 3-phase power. It features an integrated condensate evaporation system with a safety overflow. The housing is constructed from galvanized sheet steel with a powder-coated cover (RAL 7035). Dimensions are 1680 x 1410 x 790 mm, and the net weight is 434 kg. The electrical equipment has an IP 54 degree of protection. Ideal for high-capacity cooling applications in demanding industrial environments.
- 37kW cooling capacity for high-demand industrial applications
- R407C refrigerant for efficient heat exchange
- 400/460V 3-phase power supply for industrial compatibility
- IP54 protection rating for reliable operation in harsh environments
- Integrated condensate evaporation system with safety overflow
- Galvanized steel housing with powder-coated RAL 7035 cover
- Dimensions: 1680 x 1410 x 790 mm, Weight: 434 kg
Specifications
Color | Gray |
IP Rating | IP54 |
Material | Galvanized Steel |
Material | Galvanized Steel, Powder-Coated |
Series | 9000MC |
Size | 1680 x 1410 x 790 mm |
Voltage Rating | 400/460 V |
Voltage Rating | 400/460 VAC |
