Panduit UTPCH2.5MGRY - The TX5e Cat 5e UTP Patch Cord is constructed of 24 AWG, unshielded, twisted pair, stranded, CM cable with Pan-Plug modular plugs on each end. The patented tangle free latch prevents snags and provides easy release saving time on frequent moves, adds, and changes. The patch cord is 2.5 meters in length and green.
Panduit

UTPCH2.5MGRY

UPC: 074983164974

Documents & Media
Technical DrawingFull Engineering DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit UTPCH2.5MGRY is a TX5e Category 5e Unshielded Twisted Pair (UTP) patch cord, engineered for reliable network connectivity. This 2.5-meter patch cord features 24 AWG stranded CM cable, ensuring flexibility and durability for frequent moves, adds, and changes within your network infrastructure. It is terminated with Pan-Plug modular plugs on both ends, providing a secure and standard connection. A key feature of this patch cord is its patented tangle-free latch design. This innovative latch mechanism prevents snags during installation or relocation, significantly reducing setup time and minimizing the risk of cable damage. The green color coding aids in easy identification and management of network cables, particularly in complex patch panel environments. Manufactured in the US, this Panduit patch cord adheres to high-quality standards for consistent performance in data transmission. Its construction is suitable for general-purpose horizontal or building cable applications, supporting Ethernet and other data networking protocols up to the Category 5e standard. The UTPCH2.5MGRY is an essential component for structured cabling systems requiring dependable and easily manageable patch connections. Its specific length of 2.5 meters offers a practical solution for moderate distances between network devices and patch panels, optimizing cable management and reducing excess
  • 2.5-meter length for flexible network connections
  • 24 AWG stranded CM cable for durability and flexibility
  • Pan-Plug modular plugs for secure termination
  • Patented tangle-free latch prevents snags and aids in easy release
  • Green color for easy cable identification and management

Specifications

Application
(1) Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet) (2) 155 Mb/s ATM, 622 Mb/s ATM (3) Token ring 4/16 (4) Voice/data systems (5) Voice over Internet Protocol (VoIP)
Boot Type
Modular Plug
Cable Type*
U/UTP
Color
Green
Conductor Material
Copper
Jacket Material
Polyvinyl chloride
Length
8.2 In.
Outside Diameter
0.22 In.
Performance Level*
Category 5e
Plug Type
Modular Plug
Standard
Exceeds all ANSI/TIA-568.2-D Category 5e and ISO 11801 Class D standards for all frequencies from 1 to 100 MHz; Meets ANSI/TIA-1096-A (formerly FCC Part 68); IEC 60603-7; UL 1863 and CAN/CSA-C22.2 (UL File E129886), RoHS Compliant, Supports IEEE 802.3af/8
Temperature Rating
140 F
Type
Patch Cord
Wire Size
24 AWG
Package Dimensions (L x W x H)
11 IN x 9 IN x 1.5 IN
Package Weight (Imperial)
0.135 lbs
