Panduit STPK6X3MGR - The TX6A 10Gig Keyed Cat 6A STP Patch Cord is a 3-Meter, Green cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable. It's equipped with a TX6A 10Gig Keyed Modular Plug on one end and a Non-Keyed Modular Plug on the other. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Panduit

STPK6X3MGR

UPC: 074983337200

Documents & Media
Technical BulletinTechnical DrawingFull Engineering Drawing

Contact for Pricing

Minimum Qty: 10

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit STPK6X3MGR is a 3-meter, green TX6A 10Gig Keyed Cat 6A Shielded Twisted Pair (STP) patch cord designed for high-speed network connectivity. Constructed with 26 AWG stranded CM/LSZH cable, this cord ensures reliable data transmission for 10 Gigabit Ethernet applications. It features a unique keyed modular plug on one end, providing enhanced security and preventing accidental disconnections or misconfigurations in critical network segments. The other end is equipped with a standard non-keyed modular plug. A key feature is the tangle-free latch, engineered to prevent snagging during installation or maintenance and to facilitate a quick, hassle-free release. This streamlines moves, adds, and changes (MACs) within your network infrastructure, reducing downtime and labor costs. Furthermore, the STPK6X3MGR is enabled with Panduit's RapidID technology. Each cord comes with pre-installed barcodes, allowing for simple and efficient port mapping when used with RapidID software. This capability significantly simplifies network management and troubleshooting by providing immediate identification of cable connections. Manufactured in the USA, this patch cord meets stringent quality standards for demanding network environments.
  • 3-meter length in a vibrant green color
  • TX6A 10Gig Keyed Cat 6A STP Shielded Twisted Pair cable
  • 26 AWG stranded CM/LSZH construction for reliable performance
  • Keyed modular plug for enhanced security and error prevention
  • Tangle-free latch for snag-free installation and fast release
  • RapidID enabled with pre-installed barcodes for simplified port mapping

Specifications

Application
(1) 10GBASE-T Ethernet (2) Data center I/O consolidation(3) Data center server virtualization (4) Consolidation of network interconnects(5) Back-bone aggregation(6) Parallel processing and high speed computing
Boot Type
Non-Keyed Modular Plug
Cable Type*
S/FTP
Color
Green
Conductor Material
Copper
Jacket Material
LSZH Material
Length
9.84 In.
Outside Diameter
0.235 in
Outside Diameter
5.969 mm
Performance Level*
Category 6A
Plug Type
Keyed Modular Plug
Standard
Exceeds the requirements of ANSI/TIA/EIA568-B.2-10, ISO 11801 Class EA Edition 2.1, and IEEE 802.3an-2006, meets ANSI/TIA-968-A, meets IEC 60603-7, meets IEEE 802.3af and draft requirements of IEEE 802.3at for PoE Plus, UL 1863, RoHS Compliant
Temperature Rating, Maximum
140 F
Temperature Rating, Maximum
60 C
Temperature Rating, Minimum
140 F
Temperature Rating, Minimum
60 C
Type
Keyed Patch Cord
Wire Size
26 AWG
Package Dimensions (L x W x H)
11 IN x 9 IN x 1.5 IN
Package Weight (Imperial)
0.26 lbs
