Contact for Pricing
Minimum Qty: 25
Multiplier: 25
*Contact for lower quantities*
Overview
- Category 6A performance for 10GBASE-T applications up to 500 MHz
- 28AWG F/UTP construction with CM/LSZH jacket for fire safety
- 0.5m length for flexible connectivity in data centers and enterprise networks
- Violet color coding for easy identification in structured cabling systems
- 25-pack bundle for efficient stock management and rapid deployment
Specifications
Application | (1) 10GBASE-T Ethernet(2) Data center I/O Consolidation(3) Data center server virtualization(4) Backbone aggregation(5) Parallel processing and high speed computing |
Boot Type | Modular Plug |
Cable Type* | F/UTP |
Color | Violet |
Conductor Material | Copper |
Connection Type | RJ45 |
Connection Type | F/UTP (Foiled/Unshielded Twisted Pair) |
Connection Type | RJ45 (implied by Cat 6A patch cord) |
Connection Type | F/UTP |
Frequency | 500 MHz |
Length | 1.64 In. |
Material | Copper |
Material | CM/LSZH jacket, F/UTP (foiled/unshielded twisted pair) |
Material | Copper, LSZH |
Material | Copper, CM/LSZH jacket |
Outside Diameter | 0.18 In. |
Performance Level* | Category 6A |
Plug Type | Modular Plug |
Series | Cat 6A |
Series | STP28X |
Series | Category 6A Performance |
Series | Category 6A |
Size | 0.5M |
Standard | Exceeds all ANSI/TIA-568-C.2 Category 6A and ISO 11801 Class EA Edition 2.1 electrical performance requirements; Meets ANSI/TIA-1096-A; Meets IEC 60603-7; Supports IEEE 802.3af/802.3at (48 cables in a bundle) and proposed 802.3bt type 3 and type 4 (24 cab |
Temperature Rating | 167 F |
Type | Patch Cord |
Wire Size | 28 |
Package Dimensions (L x W x H) | 10.75 IN x 8.75 IN x 3.5 IN |
Package Weight (Imperial) | 1.5 lbs |
NK6XPPG24Y
The NetKey Cat 6A UTP Flat Punchdown Patch Panel terminates 4-pair, 22 26 AWG, twisted pair cable. These Cat 6A patch panels mount to 19 inch and 23 inch racks and incude 24 ports. Each module is 100% factory tested to exceed industry standard performance requirements, and are individually serialized for traceability. The punchdown patch panel is 1 RU, made of steel, and is black.
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color GraySVNDZ-P137GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray
A802
Steel Raceway Joiner with GoldGalv finish, reinforcing plate and nuts. For use with 'A' series channel.
A238
Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC
MPNY-1000-0-C
Cable Tie Mounting Base, UV Black Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 25.14mm (0.99 Inches), Width of 25.14mm (0.99 Inches), Height of 5.08mm (0.198 Inches), Mechanical Strength 50 Newtons (11 Pounds), Hole Size #6, Synthetic Rubber Mounting Method, 100 Pack
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
Frequently Asked Questions
What is the operating temperature range?
The operating temperature range is 14°F to 167°F (-10°C to 75°C).
What are the cable specifications for STP28X7.5MGR?
The STP28X7.5MGR is a 28 AWG shielded twisted pair cable, constructed of solid copper with a nominal diameter of 0.185 in.
What is the storage temperature range?
The storage temperature range is -40°F to 158°F (-40°C to 70°C).
What compliance standards does this product meet?
The product meets ANSI/TIA-1096-A, IEC 60603-7, and is cULus Listed.
What types of PoE applications are supported?
It supports IEEE 802.3af/802.3at and proposed 802.3bt type 3 and type 4 PoE applications.
How many mating cycles can the plug withstand?
The plug is rated for 2500 mating cycles, ensuring durability.
What colors are available for the patch cords?
Patch cords are available in multiple colors including Black, Blue, Red, Yellow, Green, Orange, and Violet.
What is the identification label used for?
The identification label provides performance level, length, and quality control number for traceability.
What is the maximum length of patch cords supported?
The patch cords support channels up to 96 meters, including 90 meters of permanent links.
What is the flammability rating of the cable?
The cable has a CM / LSZH flammability rating, compliant with IEC standards.
How to Install Panduit 28 AWG Patch Cords
This guide provides step-by-step instructions for installing Panduit 28 AWG patch cords to ensure optimal performance and efficient cable management.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Prepare the installation area
Clear the installation area of any obstructions and ensure that the environment is suitable for cable management, allowing for proper airflow.
- Mount the patch cords
Securely attach the Panduit 28 AWG patch cords to the designated cable management system or rack using the provided mounting screws. Ensure that the cords are organized to prevent tangling.
- Connect the patch cords
Plug the RJ45 connectors of the patch cords into the appropriate ports on your networking equipment, ensuring a firm connection.
- Verify connections
Use a multimeter to check the continuity of the connections and ensure that all patch cords are functioning correctly.
- Test network performance
Conduct a network performance test to confirm that the installation meets the required standards for data transmission.
