Panduit PUZ6004WH-CEG - The TX6000 Category 6 unshielded U/UTP LSZH Copper Cable is constructed of 23 AWG solid copper conductors insulated with polyethylene. The copper conductors are twisted in pairs, separated by a cross-divider and covered by a low smoke zero halogen (LSZH) jacket. The white cable is supplied 305m (1000 ft.) on a reel.
Panduit

PUZ6004WH-CEG

UPC: 074983489886

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 24

Multiplier: 24

*Contact for lower quantities*

Overview

The Panduit TX6000 SKU: PUZ6004WH-CEG is a Category 6 unshielded U/UTP LSZH copper cable designed for high-speed data transmission. Constructed with 23 AWG solid copper conductors, each pair is insulated with polyethylene and twisted to minimize crosstalk. A central cross-divider further enhances pair separation and signal integrity. The cable is jacketed with a Low Smoke Zero Halogen (LSZH) material, providing enhanced safety in environments where fire retardancy and low smoke emission are critical. This white cable is supplied on a convenient 305m (1000 ft.) reel, facilitating efficient installation. This cable is engineered to support demanding network applications, including 10GBASE-T, and is compliant with ANSI/TIA 568.2-D standards. It is ETL verified for Category 6A component compliance, ensuring reliable performance for high-bandwidth needs. The PowerCat 6A UTP cable features an innovative noise-canceling aluminum/polyester isolation wrap that significantly reduces alien crosstalk (AXT), crucial for dense installations and maintaining signal quality. Its low outside diameter, 0.272" for Plenum and 0.291" for Riser, allows for improved cable density, better cooling, and easier handling during installation. The TX6000 cable is ideal for Power over Ethernet (PoE) applications, meeting IEEE 802.3bt-2018 compliance, which requires higher current carrying capabilities. It is also HDBaseT compliant, making it suitable for A/V applications up to 100m channel. The absence of grounding or bonding requirements simplifies installation. This cable is a key component for mission-critical applications, wireless access points, and any network infrastructure demanding robust and reliable performance. Manufacturer: Panduit. UNSPSC Code: 26121634.
  • Category 6 unshielded U/UTP LSZH copper cable
  • 23 AWG solid copper conductors with polyethylene insulation
  • Low Smoke Zero Halogen (LSZH) jacket for enhanced safety
  • Supports 10GBASE-T and PoE applications (IEEE 802.3bt-2018 compliant)
  • 305m (1000 ft.) reel in white

Specifications

Application
Indoor
Color
White
Conductor Material
Copper
Construction
U/UTP
Jacket Material
LSZH Material
Length
1000 FT
Number of Conductors
4
Outside Diameter
NA In.
Temperature Rating
NA F
Type
Copper Cable
Type
Bulk Copper Cable
Voltage Rating
NA V
Voltage Rating
NA V V
Weight
29/1000 ft. lb
Package Dimensions (L x W x H)
15.8 IN x 15.8 IN x 9.5 IN
Package Weight (Imperial)
36.06 lbs
Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.

PUR6504WH-UY

Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.
Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.

PFP5504WH-UY

Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.
Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.

PUP5504WH-UY

Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.
The TX6 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant PVC (CMP), White jacket. Packaged 1000 ft./305m in an easy payout carton.

PUP6C04WH-F

The TX6 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant PVC (CMP), White jacket. Packaged 1000 ft./305m in an easy payout carton.
The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.

PUR6C04WH-F

The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.
The NK5e Cat 5e U/UTP LSZH copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m in an easy payout carton.

NUL5C04WH-CE

The NK5e Cat 5e U/UTP LSZH copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m in an easy payout carton.
Copper cable, category 6A U/UTP, plenum (CMP), 4-pair, conductors are 23 AWG with FEP insulation, twisted in pairs, separated by an integrated pair divider, surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket, white.

PUP6AM04WH-UGA

Copper cable, category 6A U/UTP, plenum (CMP), 4-pair, conductors are 23 AWG with FEP insulation, twisted in pairs, separated by an integrated pair divider, surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket, white.
The TX6A Cat 6A F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMR), White jacket. Packaged 1000ft/305m on a reel

PFR6X04WH-CG

The TX6A Cat 6A F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMR), White jacket. Packaged 1000ft/305m on a reel
The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel

PFC6X04WH-CEG

The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel
The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.

PUY6AV04WH-EG

The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.
The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.

PFR6C04WH-UG

The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.
The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.

PUL6004WH-EDY

The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.

Frequently Asked Questions

What are the temperature ratings for installation and operation?

The installation temperature rating is 0°C to 50°C (32°F to 122°F), while the operational temperature rating is -20°C to 75°C (-4°F to 167°F).

What is the maximum operating voltage for this cable?

The maximum operating voltage for the cable is 80V.

What applications does this cable support?

The cable supports applications including Ethernet 10BASE-T, 100BASE-T, 1000BASE-T, and various ATM standards.

What is the cable's performance certification?

The cable is certified to exceed ANSI/TIA-568-C.2 Category 6 and ISO 11801 Class E standards.

What is the cable's conductor size?

The cable features 23 AWG solid copper conductors insulated with HDPE.

What is the maximum installation tension for the cable?

The maximum installation tension for the cable is 110 N (25 lbf).

What is the cable's diameter and weight?

The cable has a nominal diameter of 6.2mm (0.244 in.) and weighs 13 kg per 305m (29 lbs. per 1000 ft.).

What is the flame rating of the cable?

The cable has a flame rating of LSZH, compliant with IEC 60332-3-25 and other standards.

How is the cable packaged?

The cable is packaged on reels of 305 meters (1000 feet) or 500 meters (1640 feet).

What tools are recommended for installation?

Recommended tools include termination tools (EGJT or TGJT), a wire snipping tool (CWST), and a wire stripping tool (CJAST).
