Panduit

PUL6AHD04BU-EG

Name: Panduit TX6A Cat 6A U/UTP LSZH Blue Cable, 305m (1000ft), 23 AWG, IEC 60332-3, 10GBASE-T compliant.
Brand: Panduit
SKU: PUL6AHD04BU-EG
Availability: InStock

UPC: 613056858794

Documents & Media

Specification Sheet Video Clip

Contact for Pricing

Minimum Qty: 24

Multiplier: 24

*Contact for lower quantities*

Overview

The Panduit TX6A Cat 6A U/UTP LSZH Blue Cable (SKU: PUL6AHD04BU-EG) delivers high-performance, unshielded twisted-pair connectivity for mission-critical 10GBASE-T Ethernet applications. Constructed with 23 AWG solid copper conductors and HDPE insulation, this cable features a flat divider separating the four twisted pairs, ensuring optimal signal integrity and reduced crosstalk. The Vari-MaTriX Tape wrap and flame-retardant HDPE jacket provide robust mechanical protection while meeting IEC 60332-3 LSZH (Low Smoke Zero Halogen) standards for enhanced safety in plenum and riser environments. Designed for high-density installations, the TX6A supports 10GBASE-T up to 100 meters, making it ideal for data centers, enterprise networks, and PoE applications requiring up to IEEE 802.3bt-2018 compliance. The low outside diameter (0.272" plenum, 0.291" riser) improves cable management, density, and airflow, reducing installation costs and simplifying termination. Third-party ETL verified for Category 6A component compliance, this cable ensures reliable performance in demanding environments. Key applications include high-bandwidth data transmission, wireless access points, HDBaseT systems, and PoE+ deployments. The blue LSZH jacket meets strict fire safety regulations, while the 305m (1,000ft) reel length provides efficient bulk packaging for large-scale projects. Compatible with ANSI/TIA 568.2-D and ISO/IEC 11801 standards, the TX6A is a cost-effective solution for future-proofing network infrastructure.

23 AWG solid copper conductors with HDPE insulation for superior signal integrity
Vari-MaTriX Tape wrap and flame-retardant HDPE jacket (IEC 60332-3 LSZH compliant)
Supports 10GBASE-T up to 100m, ETL verified for Category 6A compliance
Low outside diameter (0.272" plenum, 0.291" riser) for improved cable density and handling
Ideal for PoE (IEEE 802.3bt-2018), HDBaseT, and high-bandwidth applications

Specifications

AWG size	23
Number of Pins	4
Type	Bulk Copper Cable
Type	Copper Cable
Package Dimensions (L x W x H)	15.75 IN x 15.75 IN x 9.65 IN
Package Weight (Imperial)	34.37 lbs

AP9641

UPS NTWK MGMT CARD POWERCHUTE NTWK SHUTDOWN ENVT MONITORING

PCMDS19003BK1

2U Hinged Finger Panel

SVNDZ-P167GT

VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color Gray

SVNDZ-P137GT

VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray

SVH-36-020

VH System Support Clip - Fits to Conduit Size NW/Metric 36/40, Color Gray

ACB21

Conduit Clip with Integral Lid, Nominal Conduit Size 21mm, Polyamide (Nylon) 66, Black

A802

Steel Raceway Joiner with GoldGalv finish, reinforcing plate and nuts. For use with 'A' series channel.

A238

Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC

MPNY-1000-0-C

Cable Tie Mounting Base, UV Black Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 25.14mm (0.99 Inches), Width of 25.14mm (0.99 Inches), Height of 5.08mm (0.198 Inches), Mechanical Strength 50 Newtons (11 Pounds), Hole Size #6, Synthetic Rubber Mounting Method, 100 Pack

MPNY-1000A-9-C

Cable Tie Mounting Base, Natural Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 28.58mm (1.125 Inches), Width of 28.58mm (1.125 Inches), Height of 5.08mm (0.20 Inches), Acrylic Adhesive Method, 100 Pack

TY29MX

High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)

TYH27M

Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)

DDW-120

Ethernet SHDSL Extender

PS-60

Power supply for DIN-rail

ARH 1656

DIN Rail ? DIN 35

REFK1904231BK1

24U 21.34W 31.5D CABINET BLK

ST4803PDGM

Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .

3085

Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included

ECK19H

Cable Manager, fits 19-inch open rack, Black, Steel

PPFS19010BK

6U PERF PANEL

STP6X12MIG

This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.

F62ERLNSNSNM002

OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL

CESUM3-C15

Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.

NUL6C04WH-FE

The NK6 Cat 6 U/UTP LSZH copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m in an easy payout carton.

PUP6004BU-ULPZ

The TX6000 Enhanced Category 6 U/UTP Copper Cable is constructed of 23 AWG conductors with FEP/polyolefin insulation. The copper conductors are twisted in pairs, separated by a cross-divider and covered by a low smoke, flame-retardant (CMP) blue jacket supplied 305m (1000 ft.) in a reel in a carton. The cable has been tested as part of the TX6000 Enhanced Copper Cabling System and exceeds the ANSI/TIA-568.2-D and ISO 11801 Class E electrical channel requirements with guaranteed headroom.

PUP6XHD04OR-G

The TX6A Cat 6A U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP insulation. The copper conductors shall be twisted in pairs. All four pairs shall be surrounded by a metallic alien crosstalk barrier tape and covered by a flame retardant PVC (CMP), Orange jacket. Packaged 1000 ft./305m on a reel.

PUP6C04WH-WLPZ

The TX6 Cat 6 U/UTP copper cable is constructed of 23 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The white, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.

PUP6C04YL-F

The TX6 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs. All four pairs shall be covered by a flame retardant PVC (CMP), Yellow jacket. Packaged 1000 ft./305m in an easy payout carton.

PUP6C04BL-W

The TX6 Cat 6 U/UTP copper cable is constructed of 24 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The black, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.

NUL6C04BU-FE

The NetKey Cat 6 U/UTP copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a HDPE flame-retardant jacket. The blue, LSZH (IEC 60332-1, EuroClass Dca-s2,d2,a1) cable is supplied 305 meters (1,000 feet) to an easy pay-out carton.

PUP6004IG-ULP

The TX6000 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMP), Gray jacket. Packaged 1000 ft./305m on a reel in a box.

PUP6004WH-ULP

The TX6000 Cat 6 U/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMP), White jacket. Packaged 1000 ft./305m on a reel in a box.

PUP6004BL-WLPZ

The TX6000 Cat 6 UTP copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin (CMP) insulation. The copper conductors shall be twisted in pairs, separated by a cross-divider and covered by a low smoke, flame-retardant, plenum-rated, black jacket.

PUP6C04IG-WLPZ

The TX6 Cat 6 U/UTP copper cable is constructed of 23 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The intl.gray, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.

PUP6C04IG-W

The TX6 Cat 6 U/UTP copper cable is constructed of 24 AWG copper conductors with FEP/HDPE insulation. The copper conductors are twisted in pairs. All four pairs are surrounded by a PVC flame-retardant jacket. The international gray, plenum (CMP) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.

Frequently Asked Questions

What is the cable diameter of the PUL6AHD04BU-EG?

The cable diameter is 6.2mm (0.245 in.) nominal.

What is the maximum operating voltage?

The maximum operating voltage is 80 V.

Is the cable PoE compliant?

Yes, it meets IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt for PoE applications.

What is the weight of the cable per 1000 ft?

The cable weighs 28.2 lbs. per 1000 ft.

What is the DC resistance per 100m?

The DC resistance is less than 9.38 Ohm per 100m (328 ft.).

What is the maximum operating temperature?

The maximum operating temperature is 75°C (167°F).

What is the temperature rating during installation?

The temperature rating during installation is 0°C to 60°C (32°F to 140°F) for LSZH and 0°C to 50°C (32°F to 122°F) for CM/CMR.

What is the minimum bend radius for installation?

The minimum bend radius is 4 times the cable diameter.

What is the maximum installation tension?

The maximum installation tension is 25 lbf (110 N).

What applications is the cable suitable for?

It is suitable for 10GBASE-T Ethernet, data center I/O consolidation, and high-speed computing.
