Contact for Pricing
Overview
- 100G QSFP28 passive modular connectors on each end
- 3-meter length twinaxial copper cable assembly
- 30AWG cable gauge for reliable signal transmission
- Direct attach, plug-and-play connectivity
- Ideal for data center, enterprise, and campus networks
Specifications
Color | Black |
Connection Type | QSFP28 Modular Connector |
Connection Type | QSFP28 |
Jacket Material | Polyvinyl Chloride (PVC) |
Material | Copper |
Material | Copper (Twinaxial) |
Poles | 2P |
Poles | 2-pair |
Series | QSFP28 |
Series | PQSF |
Series | PQSF2PXA3MBL |
Size | 3 M |
Size | 30AWG, 3m |
Size | 3 meters |
Standard | Compliant to SFF-8431, SFF-8432 and SFF-8472, IEC flame compliance: IEC 60332, 60333, 60324, CE and RoHS Compliant |
Temperature Rating, Maximum | 176 F |
Temperature Rating, Maximum | 80 C |
Temperature Rating, Minimum | 176 F |
Temperature Rating, Minimum | 80 C |
Package Dimensions (L x W x H) | 14 IN x 16 IN x 2 IN |
Package Weight (Imperial) | 0.28 lbs |
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color GraySVNDZ-P137GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray
A802
Steel Raceway Joiner with GoldGalv finish, reinforcing plate and nuts. For use with 'A' series channel.
A238
Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC
MPNY-1000-0-C
Cable Tie Mounting Base, UV Black Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 25.14mm (0.99 Inches), Width of 25.14mm (0.99 Inches), Height of 5.08mm (0.198 Inches), Mechanical Strength 50 Newtons (11 Pounds), Hole Size #6, Synthetic Rubber Mounting Method, 100 PackMPNY-1000A-9-C
Cable Tie Mounting Base, Natural Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 28.58mm (1.125 Inches), Width of 28.58mm (1.125 Inches), Height of 5.08mm (0.20 Inches), Acrylic Adhesive Method, 100 Pack
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
Frequently Asked Questions
What is the nominal outer diameter of the PQSF2PXA3MBL cable?
The nominal cable outer diameter for PQSF2PXA3MBL is 6.1 mm (0.240 inches).
What is the cable gauge for the PQSF2PXA3MBL part number?
The PQSF2PXA3MBL cable assembly uses a 30 AWG cable gauge.
What is the length of the PQSF2PXA3MBL cable?
The PQSF2PXA3MBL cable assembly has a length of 3 meters (9.8 feet).
Do these QSFP28 DAC cables require external power?
No, these are passive low power assemblies. They provide a low-cost interconnect option with no additional power draw.
What is the operating temperature range for these cables?
The QSFP28 DAC cable assemblies have a temperature range of -25°C to 80°C (-13°F to 176°F).
What data rate do these QSFP28 DAC cables support?
These QSFP28 Direct Attach Copper Cable Assemblies support 100 Gb/s data transport. They are designed for 100 Gigabit Ethernet applications.
What is the operating temperature range for these cables?
The QSFP28 DAC cable assemblies have a temperature range of -25°C to 80°C (-13°F to 176°F).
What is the nominal outer diameter of the PQSF2PXA3MBL cable?
The nominal cable outer diameter for PQSF2PXA3MBL is 6.1 mm (0.240 inches).
What data rate do these QSFP28 DAC cables support?
These QSFP28 Direct Attach Copper Cable Assemblies support 100 Gb/s data transport. They are designed for 100 Gigabit Ethernet applications.
Do these QSFP28 DAC cables require external power?
No, these are passive low power assemblies. They provide a low-cost interconnect option with no additional power draw.
