Panduit NUL6C04WH-FE - The NK6 Cat 6 U/UTP LSZH copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m in an easy payout carton.
Panduit

NUL6C04WH-FE

UPC: 613056733343

Contact for Pricing

Minimum Qty: 24

Multiplier: 24

*Contact for lower quantities*

Overview

The Panduit NK6 Cat 6 U/UTP LSZH copper cable (SKU: NUL6C04WH-FE) is engineered for reliable data transmission in demanding environments. Constructed with 24 AWG copper conductors, this cable features High-Density Polyethylene (HDPE) insulation for robust performance. The conductors are meticulously twisted into pairs and separated by a cross divider, ensuring optimal signal integrity and minimizing crosstalk. All four pairs are encased in a flame-retardant HDPE jacket with Low Smoke Zero Halogen (LSZH) properties, providing enhanced safety in case of fire. The jacket is finished in a clean white color for easy identification and management within network infrastructure. This cable is specified to support Category 6 performance standards, making it suitable for Gigabit Ethernet networks and other high-speed data applications. It is ETL verified to the TIA-568.2-D Category 6 standard, guaranteeing electrical performance characteristics across the entire frequency range. The cable is packaged in a convenient 1000 ft. (305m) easy payout carton, designed to minimize tangles and facilitate efficient installation. Manufactured in the USA, this Panduit cable is a key component for building robust and safe network cabling systems. Its LSZH jacket makes it an excellent choice for installations where fire safety and reduced smoke emission are critical concerns, such as in public buildings, data centers, and educational facilities. The 24 AWG conductor gauge offers a balance of flexibility and conductivity for typical network runs. The U/UTP (Unshielded Twisted Pair) construction simplifies termination and reduces overall cable diameter compared to shielded alternatives, while the internal cross divider further enhances pair separation and performance. This product is compliant with RoHS standards, ensuring environmental responsibility in its manufacturing and materials.
  • Category 6 U/UTP copper cable for Gigabit Ethernet
  • 24 AWG copper conductors with HDPE insulation
  • Flame-retardant HDPE (LSZH) white jacket for safety
  • Internal cross divider for improved signal integrity
  • 1000 ft. (305m) easy payout carton for efficient installation

Specifications

AWG size
24
Color
White
Construction
LSZH Material
Material
Copper, HDPE, LSZH
Number of Pins
4
Size
24 AWG
Type
Copper Cable
Type
Bulk Copper Cable
Package Dimensions (L x W x H)
9.3 IN x 16.9 IN x 16.9 IN
Package Weight (Imperial)
27.8 lbs
