Contact for Pricing
Overview
- Recessed mounting for flush ceiling installation
- Powder-coated white door with keyed lock for security
- Central consolidation point for copper, fiber, and ONT transitions
- Designed for air handling spaces above drop ceilings
- Manufactured in the USA for reliability
Specifications
Color | White |
Connection Type | Copper, Fiber, ONT |
Depth | 6.9 in |
Depth | 175.26 mm |
Material | Steel |
Material | Powder Coated Metal |
Material | Steel (Powder Coated) |
Material | Steel (powder-coated) |
Mounting Type | Recessed |
Series | MSICE |
Size | 24 |
Size | Multi-Purpose In-ceiling Enclosure |
Size | 24" (implied by model number) |
Size | 24 (model-specific) |
Standard | RoHS, UL 2416, UL 2043 |
Type | In-Ceiling Enclosure |
Width | 23.41 in |
Width | 594.614 mm |
Package Dimensions (L x W x H) | 29.25 IN x 29.25 IN x 12.125 IN |
Package Weight (Imperial) | 30.4 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What are the dimensions of the MSICE24 enclosure?
The MSICE24 enclosure measures 22.5 inches in height, 22.5 inches in width, and 6.9 inches in depth.
What is the load capacity of the MSICE24?
The MSICE24 enclosure has a load capacity of 35 lbs (16 kg).
How is the MSICE24 mounted?
The MSICE24 is designed for recessed in-ceiling mounting.
What materials is the MSICE24 made from?
The enclosure is constructed from 18 gauge steel.
What safety certifications does the MSICE24 have?
The MSICE24 is compliant with RoHS, UL 2043, and UL 2416 standards.
Does the MSICE24 have a locking mechanism?
Yes, the enclosure features a hinged lockable door to protect against damage and tampering.
What type of equipment can be housed in the MSICE24?
The enclosure can house AV or ONT devices, copper connections, and fiber connections.
What accessories are available for the MSICE24?
Accessories include a device shelf, grounding kit, and cool boot for cable entry points.
What is the installation process for the MSICE24?
The enclosure features cable knockout openings and a removable equipment mounting plate for easier installation.
Can the MSICE24 be used in residential applications?
Yes, the MSICE24 is suitable for both commercial and residential deployments.
How to Install the MSICE24 In-Ceiling Enclosure
This guide provides step-by-step instructions for installing the MSICE24 In-Ceiling Enclosure, including mounting, wiring, and grounding procedures.
Estimated time: 1h
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Grounding cable, Nuts and washers
- Install threaded rods
Install four 1/2" diameter threaded rods to the building structure at the corners of the enclosure. Secure each rod with a nut and washer above and below the support bracket to ensure the enclosure is level and not supported by the ceiling grid.
- Ground the enclosure
Run a grounding cable from the Telecommunications Grounding Busbar (TGB) to the enclosure. Attach the grounding cable to one of the M5 earthing studs on the enclosure base, ensuring no other conductors are connected to this stud.
- Route cables
Use the conduit knockouts for cable ingress/egress. If using the gland plate, ensure it is installed to maintain enclosure ingress protection ratings. Alternatively, replace it with the MSICECB Cool Boot for higher cable capacity.
- Install electrical junction box
If required, install an electrical junction box using the provided M5 studs and flange nuts. Ensure that all electrical components are installed by a qualified professional according to local building codes.
- Bond the door
If using the MSGK door bonding kit, attach the bonding jumper to the specified M5 bonding studs on the enclosure and the door to ensure proper grounding.
