Overview
- Holds and secures up to four FST24S fiber splice trays
- Includes mounting hardware and Panduit Tak-Ty Cable Ties
- Compatible with FMT1, FMT2, FMD1, and FMD2 rack mount trays
- Black color for standard rack integration
- Supports vertical or horizontal mounting configurations
Specifications
Application | Fiber stacking holder used with fiber splice tray |
Color | Black |
Depth | 13 in |
Depth | 330.2 mm |
Material | Aluminum |
Material | Aluminium |
Mounting | NA In. |
Standard | RoHS Compliant |
Type | Fiber Stacking Holder |
Width | 7 in |
Width | 177.8 mm |
Package Dimensions (L x W x H) | 13.4 IN x 10.3 IN x 4.4 IN |
Package Weight (Imperial) | 0.96 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the size of the FMT1 tray?
The FMT1 tray measures 19.00"W x 1.77"H x 11.16"D.
What is the size of the FMT2 tray?
The FMT2 tray measures 19.00"W x 3.48"H x 11.16"D.
What materials are used in the trays and drawers?
Trays, drawers, and pre-loaded trays are constructed of steel material.
What is the maximum number of splice trays the FSTHED can hold?
The FSTHED splice tray holder accepts up to 4 FST24S splice trays.
How many fibers can the trays manage?
Opticom® Trays can manage up to 96 fibers, while Drawers can also manage up to 96 fibers.
What type of cable entry options are available?
The trays and drawers provide side and rear cable entry options.
Can the trays be mounted on different rack sizes?
Yes, the preloaded trays can mount flush on 19" or 23" racks and also mount 2.0" recessed on 19" racks or cabinets.
What type of adapter panels are compatible?
The trays can use any standard FAP or FMP series adapter panel.
What is the purpose of the removable patch panel?
The removable patch panel allows for rear access from the front of the unit.
What is the function of the bend radius control clips?
The built-in bend radius control clips help manage the cable routing within the trays and drawers.
How to Install the FSTHED Opticom HD Splice Tray Holder
This guide provides step-by-step instructions for installing the FSTHED Opticom HD Splice Tray Holder in a 1RU enclosure.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Cable ties
- Prepare the enclosure
Ensure the 1RU enclosure is clean and free of debris. If necessary, fold the tabs of the splice tray holder in half to fit the enclosure.
- Mount the splice tray holder
Secure the FSTHED splice tray holder to the enclosure using the provided mounting screws. Ensure it is firmly attached and level.
- Organize the cables
Use cable ties to neatly organize and secure any incoming or outgoing cables to the splice tray holder, ensuring there are no loose cables.
