Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- 2.0mm LSZH jacket for fire safety compliance
- LC Uniboot pull-boot connectors for simplified cable management
- OM4+ Signature Core fiber for enhanced bandwidth and reduced modal dispersion
- Ultra Low insertion loss for minimal signal degradation
- 009-meter length for flexible deployment in data centers and enterprise networks
Specifications
Application | Provide interconnect and cross-connect of applications in entrance facilities, telecommunications rooms, data centers, at the desk and network applications to interconnect pre-terminated cassettes in main distribution, horizontal distribution, and equipmen |
Boot Type | LC Duplex Uniboot |
Color | Aqua |
Flammability Rating* | LSZH |
Number of Cores | 2 |
Plug Type | LC-Duplex Uniboot |
Standard | RoHS Compliant. Meets or exceeds ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-3 (FOCIS-3), TIA-604-10 (FOCIS-10), All patch cord components meet the requirements of Directive 2002/95/EC. |
Temperature Rating, Maximum | 140 F |
Temperature Rating, Minimum | 140 F |
Type | OM4+ |
Package Dimensions (L x W x H) | 9 IN x 11 IN x 1.5 IN |
Package Weight (Imperial) | 0.208 lbs |
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color GraySVNDZ-P137GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
CMSBUSCZBL
The Mini-Com Singlemode Simplex SC Adapter is a small form factor (SFF) adapter with integrated panel retention clips and are TIA/EIA-605 FOCIS-10 compatible. It connects two SC connectors in one module space and features a blue SC simplex fiber adapter along with a black module and has zirconia split sleeves.
Frequently Asked Questions
Can the polarity of these patch cords be changed?
Yes, the connector allows easy polarity change in the field without mechanical components that can be unfastened or misplaced.
What jacket materials are available for these patch cords?
The patch cords are available with plenum (OFNP) or low smoke zero halogen (LSZH) rated jacket materials.
What fiber types are supported by these patch cords?
These patch cords support OS2, OM4, OM4+, and OM5 fiber types.
What connector end face types are available?
Connectors are available with UPC end faces for multimode and singlemode, and APC end faces for singlemode only.
What is the cable outside diameter?
The cable outside diameter is 2.0mm.
What is the connector durability rating?
The connector durability is rated for 500 cycles.
What is the minimum bend radius for the cable?
The minimum bend radius for the cable is 20mm.
Are these patch cords RoHS compliant?
Yes, all patch cord components meet the requirements of Directive 2011/65/EU for RoHS compliance.
What are the operating and storage temperature ranges?
The operating and installation temperature range is -10°C to 60°C, and storage/shipping is -40°C to 70°C.
What are the insertion loss specifications?
Optimized insertion loss is 0.15dB max for OM4, OM4+, OM5 and 0.25dB max for OS2. Ultra insertion loss is 0.10dB max for OM4, OM4+, OM5.
