FC-ICCP1MBU

The TX6A FieldCord Connector provides Category 6A performance and is compatible with Category 6 and 5e UTP systems.

It is compatible with 4-pair, 22–26 AWG solid or stranded unshielded twisted pair cable with specific conductor insulation and overall cable diameters.

Yes, it supports IEEE 802.3af/at (PoE/PoE+) and 802.3bt type 3 and 4 (PoE++) applications, including Power over HDBaseT up to 100 watts.

The operating temperature range for the TX6A FieldCord Connector is +14°F to +167°F (-10°C to +75°C).

The plug is rated for 2500 mating cycles, ensuring durability for repeated connections.

Yes, the FieldCord Splice Connector can be re-terminated up to 20 times without needing additional parts.

Compatible cables have conductor insulation diameters up to 0.060 in. (1.52mm) and overall cable O.D. from 0.189 in. to 0.272 in. (4.80mm to 6.91mm).

Its small diameter 23 AWG cable and ultra-compact RJ45 plug allow it to fit into tight cable routing paths and small port spaces.

Yes, it exceeds ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA Channel performance requirements.

Recommended tools include the EGPT Compact Termination tool, CJAST Cable jacket stripping tool, and CWST Wire snipping tool.
