Contact for Pricing
Overview
- Includes 2 wall beams for aisle containment systems
- 600mm length per beam for modular installation
- White finish for visual integration and heat reflection
- Compatible with Panduit Net-Contain accessories
- US-made for reliability and compliance
Specifications
Color | White |
Material | Steel |
Standard | RoHS Compliant |
Type | Wall Beam |
Width | 5.25 in |
Width | 133.35 mm |
Package Dimensions (L x W x H) | 41.34 IN x 6.3 IN x 3.54 IN |
Package Weight (Imperial) | 26.4 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
Can this system be used with non-Panduit cabinets?
Yes, the system is compatible with all major cabinet brands and sizes.
Is the system suitable for existing data centers?
Yes, it can retrofit in both Brownfield and Greenfield applications.
Can cabinets be easily moved in and out?
Yes, cabinets can be rolled in and out without disturbing the containment structure.
What is the height adjustment range of the system?
The system height is adjustable from 42 RU to 52 RU.
What types of containment does the system offer?
The system offers roof containment for Cold Aisle and vertical wall containment for Hot Aisle.
How is unoccupied cabinet space sealed?
Unoccupied cabinet space is sealed with full height blanking panels and tool-less blanking panels.
Does the system require moving parts?
No, this passive system contains no moving parts, enhancing energy efficiency.
What is the installation requirement for the system?
The system can be deployed on raised or slab floors without disrupting existing equipment.
What is the maximum aisle width supported?
The system supports aisle widths of 900mm, 1200mm, and 1800mm.
What materials are used for the containment system?
The system is comprised of wall beams, end-of-row frames, and sliding doors.
How to Install the CUWBSS07ST01W1 Wall Beam
This guide provides step-by-step instructions for installing the CUWBSS07ST01W1 wall beam, including mounting, wiring, and initial setup.
Estimated time: 45m
Tools needed:
Screwdriver, Drill, Level
Supplies needed:
Mounting screws, Wall beam clamps, Connectors, Flap seals, Hardware kit
- Prepare the installation area
Clear the installation area of any obstructions and ensure the wall surface is clean and level.
- Mount the wall beam
Align the CUWBSS07ST01W1 wall beam with the desired height on the wall. Use a level to ensure it is straight, then secure it in place using the provided mounting screws.
- Attach the wall beam clamp
Install the wall beam clamp onto the mounted wall beam. Ensure it is tightly secured to prevent any movement.
- Connect the wall beam ganging bracket
Attach the wall beam ganging bracket to the wall beam using the included hardware. This will allow for additional wall beams to be connected if necessary.
- Install the flap seal
Attach the flap seal to the wall beam clamp to ensure a tight seal against any airflow or contaminants.
- Verify installation
Double-check all connections and ensure that the wall beam is securely mounted and level. Make any necessary adjustments.
