Contact for Pricing
Overview
- Designed for 4-foot (1200mm) aisle containment systems.
- Supports cabinets with 48 or 51 RU height.
- Integrates with cabinet-supported cold/hot aisle containment.
- Durable black finish for aesthetic compatibility.
- Enhances data center thermal management and cooling efficiency.
Specifications
Color | Black |
Depth | 3.44 In. |
Material | Steel |
Material | Metal (assumed) |
Material | Steel/Metal (implied) |
Mounting Type | Cabinet-mounted |
Mounting Type | Sliding Door Frame Adapter |
Series | Net-Contain |
Size | 4-foot (1200mm) aisle |
Size | 4-foot (1200mm) aisle, 48 or 51 RU cabinets |
Standard | RoHS Compliant |
Type | Cabinet Door Frame Adapter |
Width | 78.3 in |
Width | 1988.82 mm |
Package Dimensions (L x W x H) | 102 IN x 30 IN x 6 IN |
Package Weight (Imperial) | 63.9 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What heat loads can the Net-Contain system manage?
The system can address heat loads up to 20kW per cabinet, enabling dense server applications and eliminating data center hot spots.
What Panduit products are compatible with this system?
This integrated system is compatible with Net-Access™ N-Type and S-Type Cabinets, FiberRunner®, and Wyr-Grid® Overhead Cable Routing Systems.
What are the height options for adjustable vertical walls?
Adjustable vertical walls are available in 16 inches – 26 inches H, 26 inches – 38 inches H, and 38 inches – 66 inches H for various cabinet widths.
What are the dimensions of the End of Row Sliding Doors?
The End of Row Sliding Doors (CUD1SD* and CUD2SD*) are 2134 mm H x 1422 mm W.
Does the sliding door frame adapter require floor drilling?
Yes, drilling into the floor would be required to install the door adapter kit.
What aisle widths do End of Row Caps support?
End of Row Caps are available for 1200mm and 1800mm aisle widths, supporting various RU heights.
What are the benefits of a passive containment system?
A passive system contains no moving parts, providing more efficiency than fan-driven products and eliminating acoustical noise in the data center for improved system reliability.
What RU heights does the C2SDT9W04DAB1 adapter support?
The C2SDT9W04DAB1 Sliding Door Frame Adapter is designed for 4-foot aisles and 48/51 RU tall cabinets.
How does the system improve thermal performance?
It allows raising the supply air set point temperature, increasing the thermal efficiency of cooling units and reducing cooling energy cost up to 25 – 30%.
What are the available widths for adjustable vertical walls?
Adjustable vertical walls are available for 600mm, 700mm, and 800mm wide Net-Access™ N-Type and S-Type Cabinets.
How to Install the C2CAC08F04IRB1 Ceiling Structure
This guide provides step-by-step instructions for installing the C2CAC08F04IRB1 ceiling structure, including mounting, wiring, and initial configuration.
Estimated time: 1h
Tools needed:
Screwdriver, Level, Wire strippers
Supplies needed:
M5 screws, Foam seal, Ceiling panels, Aisle beam, Ceiling panel stops
- Install the Aisle Beam
Secure the aisle beam to the designated mounting points using M5 screws. Ensure the beam is level before tightening.
- Attach Ceiling Panel Stops
Install the ceiling panel stops at the ends of the aisle beam using M5 screws. Ensure they are securely fastened to prevent panel movement.
- Mount Ceiling Panels
Align the ceiling panels with the aisle beam and panel stops. Secure each panel in place using the provided hardware, ensuring a tight fit.
- Apply Foam Seal
Cut the foam seal to the appropriate length and apply it along the edges of the ceiling panels to ensure a tight seal against air leakage.
- Verify Installation
Check all connections and ensure that the ceiling structure is stable and secure. Use a level to confirm that the panels are properly aligned.
