Contact for Pricing
Minimum Qty: 50
Multiplier: 50
*Contact for lower quantities*
Overview
- Multi-Purpose Connector for versatile industrial use
- Ensures reliable connectivity in demanding environments
- Durable construction for long-lasting performance
- Manufactured by NSi Industries in the USA
- Designed to meet industry standards for operational efficiency
Specifications
Angle | 180 Deg |
Application | Recommended cable types with 14/2 or 12/2 nonmetallic sheath cable (NM-B), steel/aluminum 14/2 to 12/2 armored cable (AC) or metal clad (MC) cable, or steel/aluminum flexible metal conduit (FMC). Multi-Purpose connector fits 1/4" knockouts, including knoc |
Conductor Range | 14/2 to 12/2 |
Connector Type | Two-Screw, Strap Type |
Finish | Ball burnish |
Material | Zinc Die Cast |
Number Of Conductors | 1 Cable |
Size | 1/4 IN |
Special Features | HCF |
Standard | UL |
Trade Size | 3/8 IN |
Type | Connector |
Package Weight (Imperial) | 0.064 L |
Package Weight (Metric) | 0.029 kg |
Similar Products
560-DC2
Conductor Range: 14/2 to 10/3 (.44" - .61"0)
Size: 3/8 IN
Special Features: With Tri-Drive Screw
561-DC2
Application: For use with AC/MC/HCF: 10/4 (.61" 0 min) to 8/3 (.87" 0 max)
Conductor Range: 10/4 (.61" 0min) to 8/3 (.87" 0 max)
Size: 3/4 IN
565-DC2
Conductor Range: 14/2 (.38" 0 min) to 10/3 (.53" 0 max)
Size: 1/2 IN
Special Features: CSA listed for use with 14/2 to 10/3 ACG90
Frequently Asked Questions
What is the trade size of the connector?
The trade size of the connector is 1/4 inch.
What material is the connector made of?
The connector is made of zinc die cast.
How many connectors are in a standard package?
A standard package contains 500 connectors.
What is the catalog ID for the connector?
The catalog ID for the connector is 563-DC2.
What cable types are compatible with the connector?
The connector is compatible with 14/2 or 12/2 nonmetallic sheath cable, steel/aluminum armored cable, metal clad cable, and flexible metal conduit.
What is the finish of the connector?
The connector has a ball burnished, mirror smooth finish.
What are the dimensions of the connector?
The dimensions are 1-3/16 inches for A, 3/4 inch for B, and 3/8 inch for C.
What is the UPC number for the connector?
The UPC number for the connector is 78174715563.
What certifications does the connector have?
The connector meets NEMA Standard FB-1 and UL Standard UL-514B.
