NSI Industries
1103B
UPC: 786261100665
Contact for Pricing
Overview
- 24-hour mechanical timing control for precise scheduling
- 40A current rating at 120V for heavy-duty applications
- DPST (Double Pole, Single Throw) configuration for independent circuit control
- Durable metal enclosure for indoor industrial and commercial use
- Compact design for easy installation in control panels or enclosures
Specifications
Action | DPST |
Application | NSI |
Base | Screw |
Contact Rating | 120 VAC |
Current Rating | 40A |
Current Rating | 40 A |
Enclosure | NEMA 1 Metal Indoor |
Environmental Conditions | -40 to 165 F |
Frequency Rating | 60 Hz |
Initiation | Contact |
Material | Metal |
Mounting | Screw Mount |
Mounting Type | Indoor |
Number Of Pins | 12 Pair |
Number Of Poles | 1 |
Operating Temperature | -40 to 165 F |
Operating Temperature, Maximum | 165 F |
Operating Temperature, Maximum | 73.8889 C |
Operating Temperature, Minimum | -40 F |
Operating Temperature, Minimum | -40 C |
Phase | Single Phase |
Poles | DPST |
Size | L=4.687 - H=7.937 - W=2.937 IN |
Special Features | DPST 24 Hour Time Switch - Same Day On-Off Times Each Day |
Standard | UL-CSA |
Timing Range | 24 Hour |
Type | 24 Hour Time Switch |
Voltage Rating | 120 V |
Voltage Rating | 120V |
Package Dimensions (L x W x H) | 2.937 IN x 4.687 IN x 7.937 IN |
Package Dimensions (L x W x H) | 7.46 cm x 11.905 cm x 20.16 cm |
Package Weight (Imperial) | 2.400 L |
Package Weight (Metric) | 1.089 kg |
