NSi Industries 1101B-P - 24 Hour Time Switch 40A 120V SPST Out
NSI Industries

1101B-P

UPC: 786261100689

Contact for Pricing

Overview

The NSi Industries 1101B-P is a 24-hour mechanical time switch designed for reliable scheduling of electrical loads. This SPST (Single Pole, Single Throw) switch operates at 120V and can handle a maximum current of 40A, making it suitable for a variety of indoor and outdoor applications. Its durable plastic enclosure provides protection against environmental factors. The 1101B-P allows for precise daily ON/OFF programming using its internal trippers, ensuring energy efficiency and automated control for lighting, HVAC, or other electrical equipment. This unit is ideal for facilities managers, electricians, and building maintenance professionals seeking a straightforward and robust time control solution.
  • 24-hour mechanical time switch for precise scheduling
  • 40A current rating and 120V voltage operation
  • SPST (Single Pole, Single Throw) configuration
  • Durable plastic enclosure suitable for indoor/outdoor use
  • Reliable automated control for lighting, HVAC, and other loads

Specifications

Action
SPST
Application
NSI
Base
Screw
Contact Rating
120 VAC
Current Rating
40A
Enclosure
NEMA 3R Polycarbonate Indoor/Outdoor
Environmental Conditions
-40 to 165 F
Frequency Rating
60 Hz
Initiation
Contact
IP Rating
IP65
Material
Plastic
Mounting
Screw Mount
Number Of Pins
12 Pair
Number Of Poles
1
Operating Temperature
-40 to 165 F
Phase
Single Phase
Poles
SPST
Size
L=3.062 - H=8.312 - W=5.062 IN
Special Features
SPST 24 Hour Time Switch - Same Day On-Off Times Each Day
Standard
UL-CSA
Timing Range
24 Hour
Type
24 Hour Time Switch
Voltage Rating
120V
Package Dimensions (L x W x H)
3.062 IN x 5.062 IN x 8.312 IN
Package Dimensions (L x W x H)
7.7775 cm x 12.8575 cm x 21.1125 cm
Package Weight (Imperial)
1.994 L
Package Weight (Metric)
0.904 kg
