Contact for Pricing
Overview
- High-conductivity copper construction with tin-plated finish for corrosion resistance and low contact resistance
- Peep hole design enables easy visual inspection of cable insertion for compliance and safety
- UL486A/B and UL467 listed for grounding and bonding applications up to 35KV (proper installation required)
- Rated 600V with a temperature rating of 90°C; compatible with Class B or C building wire copper cable
- Color-coded and die-indexed for easy identification; 4 AWG wire range, 3/8" bolt size, 3/4" mounting spacing
Specifications
Application | Terminate, Splice, Tap Power Connectors |
Cable Size | # 4 AWG (STR) |
Color | Gray |
Environmental Conditions | 90 C |
Finish | Tin Plated |
Material | Copper |
Mounting | 3/8 Mounting Holes IN |
Number Of Holes | 2 |
Size | L=4.09 - W=.870 - OD=.340 - ID=.250 IN |
Special Features | # 4 AWG (STR) - 3/8 Mounting Holes - 3/4 Hole Spacing |
Standard | UL486A/B, UL467 (8 AWG -3/0 AWG) |
Stud Size | 3/8 IN |
Type | Long Barrel - Two Hole With Peep Hole |
Voltage Rating | 600 V |
Warranty | 1 Year |
Package Dimensions (L x W x H) | 4.09 IN x 0.87 IN x 0.34 IN |
Package Dimensions (L x W x H) | 10.3886 cm x 22.098 mm x 8.636 mm |
Package Weight (Imperial) | 2.800 L |
Package Weight (Metric) | 1.270 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
How to Install and Crimp NSI Copper Compression Connectors
Install NSI copper compression lugs or splices by preparing the conductor, selecting the correct connector size, and crimping with the approved tool and die set. Follow the strip-length and crimp-location guidance to ensure a secure, code-compliant connection.
Tools needed:
Wire brush, Approved compression crimp tool, Approved dies for the selected connector series, NSI M-250 crimp tool (for 250 MCM Class B & C copper cable), NSI M-500 crimp tool (for 500 MCM Class B & C copper cable), NSI N12ID dieless crimp tool, NSI N1240 tool
Supplies needed:
Correct NSI copper compression lug or splice connector, Copper conductor/cable, Insulation to be stripped from conductor
- Select the correct connector
Choose the proper NSI lug or splice connector for the cable size and conductor type. Verify that the connector series and size match the table for the wire gauge or MCM being installed. Use only connectors intended for concentric, compressed, or compact copper conductors.
- Strip the conductor to the correct length
Carefully strip the insulation from the conductor without nicking the strands. Strip enough length so the conductor can be fully inserted into the barrel and completely fill it. Safety warning: Do not damage or cut conductor strands during stripping.
- Clean the conductor
Wire brush the stripped portion of the conductor to remove oxide films and contamination. Make sure the stripped copper is clean before insertion.
- Insert the conductor fully
Insert the stripped conductor completely into the connector barrel. Verify that the conductor is fully seated and that the stripped portion fills the barrel before crimping.
- Crimp with the approved tool and die
Use an approved UL-listed crimp tool and the correct die set for the connector series. Follow the barrel markings for the manufacturer’s suggested crimp locations when using NSI N12ID or N1240 tools. Apply the number of crimps specified for the connector; long-barrel lugs and splices require twice the crimps shown in parentheses.
- Verify the finished connection
Inspect the crimped connector to confirm the conductor is fully seated, the crimp(s) are made at the correct locations, and the connection is secure. If the cable size is 250 MCM or 500 MCM Class B & C copper cable, use the specified NSI M-250 or M-500 mechanical crimp tool as applicable.
