Mersen Z1048684 Photovoltaic fuse gPV 1500VDC IEC 1500VDC UL Size 3L 400A With DIN Type Blades For…
Alternate Item Number: HP15NH3LGPV400B
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Mersen gPV photovoltaic fuse link
- 1500 VDC voltage rating
- 400 A current rating
- Size 3L with DIN Type Blades
- Direct Mount configuration
Specifications
Amperage Rating | 400 A |
Application | All photovoltaic applications Inverter DC input protection Re-combiner applications (sub combiner, array combiner, master combiner) |
Brand Name | Mersen |
Connection | DIN Type Blades |
Connection Material | Silver-Plated Copper |
Connection Type | DIN Type Blades |
Current Rating | 400 A |
DC Voltage Rating | 1500 V |
Frequency | Not specified |
Ip Rating | Not specified |
Material | Not specified |
Mounting | Direct Mount |
Mounting Type | Direct Mount |
Nema Rating | Not specified |
Poles | Not specified |
Series | HP15NH |
Size | 8.07 x 2.76 x 2.91 in |
Size | 205 x 70 x 74 mm |
Size | Size 3L |
Special Features | Global acceptance Low fault current interrupting capability Temperature cycle withstand capability Durable construction for enhanced system longevity High efficiency with low power losses Available in 3 versions: plain blade, direct mounted, direct mounted with striker |
Standard | IEC 60269-6 RoHS compliance UL 248-19 for fuses (pending for 1XL, 2XL) (E358319, Volume 1, Section 1) UL 4248-19 for fuseholders, Photovoltaic (E362644 Volume 1) |
Sub Brand | HelioProtection® |
Type | Photovoltaic Fuses |
Voltage Rating | 1500 VDC |
Package Dimensions (L x W x H) | 8.07 in x 2.76 in x 2.91 in |
Package Dimensions (L x W x H) | 205 mm x 70 mm x 74 mm |
Package Weight (Imperial) | 3.660 lb |
Package Weight (Metric) | 1.660 kg |
GPM-SRR90
Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount
C331156
Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20
LCC5
POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.
Frequently Asked Questions
What is the voltage rating of the Mersen Z1048684 fuse?
The Mersen Z1048684 photovoltaic fuse has a voltage rating of 1500 VDC.
What is the current rating for this photovoltaic fuse?
This Mersen photovoltaic fuse, model Z1048684, has a current rating of 400 A.
What type of blades does the Z1048684 fuse use?
The Mersen Z1048684 fuse features DIN Type Blades for direct mounting.
What size is the Mersen Z1048684 photovoltaic fuse?
The Mersen Z1048684 photovoltaic fuse is designated as Size 3L.
What is the breaking capacity of the Z1048684 fuse?
The Mersen Z1048684 fuse has a breaking capacity of 200 kA.
What is the pre-arcing I²t for the Z1048684 fuse?
The pre-arcing I²t for the Mersen Z1048684 fuse is 110000 A²s.
