Mersen W086982 - Square Body High-Speed Fuse Protistor® Size 600 gR 4000VDC IEC 80A With Striker Plain Blades
Mersen

W086982

Alternate Item Number: D600GB40C80P

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Mersen W086982 is a high-speed fuse from the Protistor® series, specifically designed for demanding DC applications. This fuse features a square body and is rated for 80 Amperes at 4000 VDC, conforming to IEC standards. Its Size 600 designation and 'gR' classification indicate its suitability for semiconductor protection, offering rapid response to overcurrents and short circuits. Equipped with a striker mechanism and plain blades, the W086982 ensures reliable contact and operational indication. Mersen DC semiconductor fuse-links, like this model, are engineered to provide superior protection for railway power and auxiliary circuits. They are developed to meet the enhanced performance requirements of modern DC equipment, often operating at elevated temperatures. Key benefits include lower I²t values, which minimize damage to protected components during short circuits, reduced power loss (watts loss), and extended service life. This fuse is an essential component for ensuring the safety and reliability of critical DC power systems.
  • Mersen Protistor® High-Speed Fuse
  • 80A Current Rating
  • 4000VDC Voltage Rating
  • Size 600, gR Classification for Semiconductor Protection
  • Includes Striker and Plain Blades for Reliable Operation

Specifications

Amperage Rating
80 A
Brand Name
Mersen
Case
Ceramic
Connection
Plain Blades
Current Rating
80 A
DC Voltage Rating
4000 V
Mounting
Bolted
Mounting Type
Plain Blades
Series
Protistor®
Size
16.38 x 2.28 x 2.48 in
Size
416 x 58 x 63 mm
Size
Size 600
Sub Brand
Protistor®
Type
Square Body High-Speed Fuse-Links DC Protection
Type Of Indicators
Striker
Voltage Rating
4000 V
Voltage Rating
4000 VDC
Wattage
92 W
Package Dimensions (L x W x H)
16.38 in x 2.28 in x 2.48 in
Package Dimensions (L x W x H)
416 mm x 58 mm x 63 mm
Package Weight (Imperial)
3.139 lb
Package Weight (Metric)
1.424 kg
