Mersen V075757 - Square Body High-Speed Fuse Protistor® Size 302 gR (gRE) 2000VDC IEC 250A With Striker L Brackets
Mersen

V075757

Alternate Item Number: D302GE20C250QF

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Mersen V075757 Protistor® is a high-speed fuse-link designed for semiconductor protection in DC power systems. Rated for 2000VDC and 250A nominal current, this Size 302 gR (gRE) fuse-link provides precise fault interruption for sensitive semiconductor devices. Its square body design with L bracket mounting ensures secure installation in industrial environments. The integrated striker mechanism triggers external signaling devices upon fuse operation, enabling rapid fault detection and system response. With a gR (gRE) classification, it meets IEC standards for general-purpose semiconductor protection. Engineered for low I²t values, the V075757 minimizes thermal stress on protected components during short circuits, reducing downtime and maintenance costs. Its low power dissipation (watts loss) improves system efficiency and extends operational life in demanding applications like railway power systems and DC auxiliary circuits. Built for reliability, this fuse-link delivers superior protection compared to conventional fuse types while maintaining compliance with modern DC equipment requirements.
  • 2000VDC voltage rating for high-power DC systems
  • 250A nominal current with gR (gRE) semiconductor protection classification
  • Square body design with L bracket mounting for secure installation
  • Integrated striker mechanism for external fault signaling
  • Low I²t and power dissipation for minimized thermal stress and improved efficiency

Specifications

Amperage Rating
250 A
Brand Name
Mersen
Case
Ceramic
Connection
L Brackets
Current Rating
250A
DC Voltage Rating
2000 V
Mounting
Bolted
Series
Protistor®
Size
Size 302
Size
10.55 x 3.03 x 6.81 in
Size
268 x 77 x 173 mm
Sub Brand
Protistor®
Type
Square Body High-Speed Fuse-Links DC Protection
Type Of Indicators
Striker
Voltage Rating
2000 V
Voltage Rating
2000VDC
Wattage
95 W
Package Dimensions (L x W x H)
12.36 in x 5.04 in x 3.35 in
Package Dimensions (L x W x H)
314 mm x 128 mm x 85 mm
Package Weight (Imperial)
4.424 lb
Package Weight (Metric)
2.006 kg
