Overview
- 3-pole pressure plate fuse holder for Midget 10x38mm fuses up to 30A
- 800VAC/1000VDC rated with 200kA AC/100kA DC SCCR
- IP20 finger-safe design for safe fuse changes without tools
- UL Recognized (E52283) and CSA Certified (Class 6225-01)
- Saves up to 15% mounting space, DIN-rail mountable for panel efficiency
Specifications
AC Voltage Rating | 800 V |
Amperage Rating | 30 A |
Application | All circuits up to 600 volts for motors, control circuits, transformers, etc… DC circuits up to 1000VDC including photovoltaic applications Non-load disconnect |
Brand Name | Mersen |
Class | Midget |
Connection | Pressure Plate |
Connection Type | Pressure Plate |
Current Rating | 30A |
DC Voltage Rating | 1000 V |
IP Rating | IP20 |
Material | Polyamide |
Maximum Operating Temperature | 80 C |
Mounting | DIN Rail |
Mounting Type | 35mm DIN-rail |
Number Of Poles | 3-pole |
Number of poles | 3 |
Operating Temperature, Maximum | 176 F |
Phase | 3 |
Poles | 3 |
Series | UltraSafe Modular |
Size | Midget 1-1/2" x 13/32" |
Size | 3.07 x 2.07 x 2.32;77.978 x 52.578 x 58.928 in;mm |
Special Features | IP20 Finger-Safe (touch safe) Optional visual blown fuse Indicator lights DIN-rail mounting Compact footprint Quick, tool-free, easy fuse change outs USM use with: ATQ, ATM, A6Y-2B, A25Z-2, TRM, OTM, A13X-2, A60Q-2, DCT, HP6M, HP10M USCC use with: ATDR, ATMR, ATQR ATM, DCT, ATMR recommended for DC applications |
Standard | UL Listed to Standard 4248- 4 (class CC) and UL Recognized to Standard 4248-1 (midget), File E52283 UL Listed to standard 4248-18 (photovoltaic), File E347822 CSA Certified C22.2 IEC 60269-2-1 and 60947-3 Compliant (USM only) |
Sub Brand | UltraSafe™ |
Type | UL/CSA Fuse Holders |
Voltage Rating | 800VAC 1000VDC |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 3.07 in x 2.07 in x 2.32 in |
Package Dimensions (L x W x H) | 77.978 mm x 52.578 mm x 58.928 mm |
Package Weight (Imperial) | 0.430 lb |
Package Weight (Metric) | 0.195 kg |
