Mersen USCC2 Fuse Holder UltraSafe™ 600VAC 600VDC Class CC 30A 2-Pole Pressure Plate IP20
Alternate Item Number: USCC2
UPC: 782001829889
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 2-pole Class CC fuse holder rated 600VAC/DC, 30A max
- IP20 finger-safe design with tool-free fuse changes
- UL-listed to 4248-4, CSA C22.2, IEC 60269-2-1 compliant
- Compact polyamide body saves up to 15% mounting space
- Optional blown-fuse indicators (90VAC/115VDC, <0.7mA leakage)
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 30 A |
Application | All circuits up to 600 volts for motors, control circuits, transformers, etc… DC circuits up to 1000VDC including photovoltaic applications Non-load disconnect |
Brand Name | Mersen |
Class | Class CC |
Connection | Pressure Plate |
DC Voltage Rating | 600 V |
Material | Glass Filled Polycarbonate |
Maximum Operating Temperature | 80 C |
Mounting | DIN Rail |
Number of poles | 2 |
Number Of Poles | 2-pole |
Operating Temperature, Maximum | 176 F |
Phase | 2 |
Size | 3.07 x 1.38 x 2.32;77.978 x 35.052 x 58.928 in;mm |
Special Features | IP20 Finger-Safe (touch safe) Optional visual blown fuse Indicator lights DIN-rail mounting Compact footprint Quick, tool-free, easy fuse change outs USM use with: ATQ, ATM, A6Y-2B, A25Z-2, TRM, OTM, A13X-2, A60Q-2, DCT, HP6M, HP10M USCC use with: ATDR, ATMR, ATQR ATM, DCT, ATMR recommended for DC applications |
Standard | UL Listed to Standard 4248- 4 (class CC) and UL Recognized to Standard 4248-1 (midget), File E52283 UL Listed to standard 4248-18 (photovoltaic), File E347822 CSA Certified C22.2 IEC 60269-2-1 and 60947-3 Compliant (USM only) |
Sub Brand | UltraSafe™ |
Type | UL/CSA Fuse Holders |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 3.07 in x 1.38 in x 2.32 in |
Package Dimensions (L x W x H) | 77.978 mm x 35.052 mm x 58.928 mm |
Package Weight (Imperial) | 0.280 lb |
Package Weight (Metric) | 0.127 kg |
Frequently Asked Questions
What is the maximum voltage and amperage for USCC fuse holders?
USCC fuse holders have a maximum rating of 600VAC/DC and 30A.
What is the maximum voltage and amperage for USM fuse holders?
USM fuse holders have a maximum rating of 800VAC and 1000VDC, with a 30A maximum amperage.
What is the operating temperature range for these fuse holders?
The fuse holders can operate in a temperature range of -40° to 85°C.
What is the suggested torque for the terminal screws?
The suggested screw torque for the terminal screws is 14.75 in-lbs.
Are these fuse holders finger-safe?
Yes, UltraSafe holders qualify as 'Finger-safe' under IEC and DIN standards with an IP20 grade of protection.
What is the flammability rating of the fuse holder body material?
The body material has a flammability rating of UL 94-V0.
Can these fuse holders be mounted on a DIN-rail?
Yes, UltraSafe holders can be snapped onto a 35mm DIN-rail.
What is the maximum power loss for these fuse holders?
The maximum power loss for these fuse holders is 3W or less.
What is the SCCR for USCC and USM fuse holders?
USCC fuse holders have a 200kA SCCR, while USM fuse holders have a 200kA SCCR for AC and 100kA for DC.
What type of wire can be used with these fuse holders?
They accept #14 to 6 AWG single conductor or #14 to 10 AWG dual conductor wire, 60/75/90°C solid/stranded copper.
