Overview
- Mersen Tri-Onic® TR-R fuses for reliable overcurrent protection.
- Class RK5 rating for effective short-circuit and overload protection.
- Time-delay characteristic safely handles motor and transformer inrush currents.
- Rated for 250VAC and 250VDC with a 25A current rating.
- Ferrule end caps ensure secure connection in compatible fuse holders.
Specifications
AC Voltage Rating | 250 V |
Amperage Rating | 25 A |
Application | Motor circuits Mains Feeders Branch circuits Transformers Service entrance equipment General-purpose equipment |
Body Material | PolyTube |
Brand Name | Mersen |
Class | Class RK5 |
Connection | Ferrule |
Connection Material | Copper |
Current Rating | 25A |
Interrupt Rating | 200 kA |
Mounting | Clip |
Series | TR-R |
Size | 2 x 0.56 in |
Size | 50.8 x 14.3 mm |
Size | 2 x 0.56;50.8 x 14.3 in;mm |
Size | Ferrule |
Special Features | Time-delay Current-limiting AC & DC rated Optional solid state SmartSpot blown fuse indicator Time-delay for motor start-ups and transformer inrush currents without nuisance opening Current-limiting for low peak let-thru current Rejection-style design prevents replacement errors (when used with recommended fuse blocks) Easy-to-read label for quick brand recognition and replacement Metal-embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching and high current limitation |
Standard | UL listed to standard 248-12 File E2137 CSA certified to standard C22.2 no. 248.12 DC listed to UL standard 248 TRS only |
Sub Brand | Tri-Onic® |
Type | Class RK5 |
Voltage Rating | 250 VAC |
Package Dimensions (L x W x H) | 2 in x 0.56 in x 0.56 in |
Package Dimensions (L x W x H) | 50.8 mm x 14.3 mm x 14.3 mm |
Package Weight (Imperial) | 0.050 lb |
Package Weight (Metric) | 0.023 kg |
