Mersen SP745PV - Surge-Trap® Pluggable SPD provides advanced overvoltage protection. Utilizing Mersen's patented TPMOV® design, which does not require fuses, a fuse holder or additional wiring in meeting the UL 1449 Third Edition standards thus providing substantial cost savings and reduced installation times. It also features a visual indicator, easy installation, fail-safe design, mechanical coding and remote monitoring. The Surge-Trap Pluggable SPD base is designed to be mounted on 35mm DIN-rail while plugs are easily replaceable upon failure without touching the base or the hassle of rewiring. 875 Volts, PV Plug .
Mersen

SP745PV

Alternate Item Number: 782001426507

UPC: 782001426507

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Mersen Surge-Trap® Pluggable SPD, SKU SP745PV, offers advanced overvoltage protection for industrial applications, specifically designed for photovoltaic (PV) systems and other low-voltage applications within appropriate enclosures. This unit features Mersen's patented TPMOV® technology, eliminating the need for external fuses, fuse holders, or additional wiring, thereby reducing installation complexity and costs. It meets ANSI/UL 1449 5th Edition, Open Type 1 SPD standards and CSA C22.2 No 269 certification, ensuring compliance and reliability. The SP745PV boasts a high surge current rating of 75kA (Imax) and a substantial Short Circuit Current Rating (SCCR) of 200kA, making it suitable for most industrial control panels. Its nominal discharge current (In) is rated between 10-20kA (8x20 μs), with a response time of less than 1 nanosecond. Installation is simplified with 35mm DIN-rail mounting and a reversible chassis for flexible cable entry. The pluggable design allows for easy module replacement upon failure without disturbing the base or rewiring, enhancing maintenance efficiency. A visual indicator (Green = Functional, Red = Replace) provides immediate status, and a remote indicator option (Form C Dry Contacts) offers status to critical control circuitry. The device operates on nominal power frequencies of 50 Hz or 60 Hz and is RoHS compliant. Its IP20 finger-safe design and UL94 V0 flammability rating contribute to a safe operating environment. The operating and storage temperature range is -40°C to +85°C. The SP745PV comes with a 5-year warranty.
  • Patented TPMOV® technology eliminates need for fuses or additional overcurrent protection.
  • 75kA Surge Current Rating (Imax) and 200kA Short Circuit Current Rating (SCCR).
  • Pluggable modules for easy replacement without rewiring.
  • 35mm DIN-rail mountable with reversible chassis for flexible installation.
  • Visual indicator and optional remote indicator for status monitoring.

Specifications

Application
AC/DC distribution Power supplies Industrial automation Telecommunications Motor controls and starter systems Programmable logic controller (PLC) applications Power transfer equipment HVAC applications AC drives UPS systems Security systems IT / Data centers Medical equipment
Brand Name
Mersen
Mounting Type
35mm DIN-rail
Series
Surge-Trap Pluggable SPD
Short Circuit Rating
200 kA
Short-Circuit Rating
200 kA
Special Features
Easy installation or retrofit DIN-rail mountable Fail-safe /self-protected design Remote indicator (optional) Visual indicator IP20 finger-safe design 2 year warranty No additional overcurrent protection devices needed Easy to replace modules
Standard
UL 1449 Third Edition Approved, File No E210793 Type 1 Component Assembly IEC 61643-1 RoHS compliant ANSI/IEEE C62.41 CE
Sub Brand
Surge-Trap®
Type
Surge-Trap® SPD
Voltage Rating
745 VAC
Voltage Rating
875 V
Package Dimensions (L x W x H)
3 IN x 2.06 IN x 1.19 IN
Package Dimensions (L x W x H)
7.62 cm x 5.2324 cm x 3.0226 cm
Package Weight (Imperial)
0.131 L
Package Weight (Metric)
0.059 kg
