Mersen S1204181 Photovoltaic fuse gG Size NH3 250A With Double indicator With Plain Blades For Clip
Alternate Item Number: NH3GG80V250
Documents & Media
Contact for Pricing
Minimum Qty: 3
Multiplier: 3
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- NH3 size fuse-link for photovoltaic applications
- 250A nominal current rating
- 800VAC voltage rating
- gG class for general purpose protection
- Double indicator for clear operational status
- Plain blades for secure connection
- Full-range breaking capacity
- Dimensions: 135 ± 2.5 mm length, 40 ± 0.8 mm width
Specifications
AC Voltage Rating | 800 V |
Amperage Rating | 250 A |
Application | General purpose cable and line protection at 800VAC Solar installation AC combiner box |
Brand Name | Mersen |
Class | Photovoltaic |
Connection | Plain Blades |
Connection Material | Silver-Plated Copper |
Interrupt Rating | 120 kA |
Mounting | Clip |
Size | 5.91 x 2.01 x 2.83 in |
Size | 150 x 51 x 72 mm |
Special Features | Low fault current interrupting capability Temperature cycle withstand capability Durable construction for enhanced system longevity High efficiency with low power losses |
Standard | IEC 60269-2 RoHS compliance |
Sub Brand | HelioProtection® |
Type | Photovoltaic Fuses |
Type Of Indicators | Double indicator |
Package Dimensions (L x W x H) | 5.91 in x 2.01 in x 2.83 in |
Package Dimensions (L x W x H) | 150 mm x 51 mm x 72 mm |
Package Weight (Imperial) | 1.731 lb |
Package Weight (Metric) | 0.785 kg |
GPM-SRR90
Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount
C331156
Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20
LCC5
POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.
Frequently Asked Questions
What is the ampere range for the NH3GG80V250 fuse-link?
The NH3GG80V250 fuse-link has a rated current of 250 A.
What is the rated voltage for these NH fuse-links?
The HelioProtection® NH fuse-links are rated for 800VAC.
What is the primary application for these HelioProtection® NH fuse-links?
These fuse-links are designed specifically for photovoltaic systems and solar installation AC combiner boxes.
What is the breaking capacity of the NH gG 800VAC fuse-links?
The breaking capacity for these fuse-links is 120 kA.
What type of fuse-links are the HelioProtection® 800VAC?
They are NH gG type, full range breaking capacity fuse-links.
What standards do these fuse-links comply with?
These fuse-links comply with IEC 60269-2 and are RoHS compliant.
What is the power dissipation for the NH3GG80V250 at rated current?
The power dissipation for the NH3GG80V250 at its rated current of 250 A is 22 W.
What is the pre-arcing I²t for the NH3GG80V250 fuse-link?
The pre-arcing I²t for the NH3GG80V250 is 110 kA²s.
What is the width of the NH3GG80V250 fuse-link?
The width of the NH3GG80V250 fuse-link is 65 mm.
What is the clearing I²t at rated voltage for the NH3GG80V250?
The clearing I²t at rated voltage for the NH3GG80V250 is 1100 kA²s.
