Mersen RF80 Fuse RF - Class H - Fast-Acting 250VAC 80A Blade
Alternate Item Number: RF80
UPC: 068938720315
Documents & Media
Contact for Pricing
Minimum Qty: 5
Multiplier: 5
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Class H fast-acting blade fuse for general-purpose overcurrent protection
- Rated 250VAC, 80A with 10,000A interrupting rating
- Precision die-cut zinc replacement link for repeatable performance
- Knurled bushings enable quick disassembly and renewal
- Suitable for short-circuit currents up to 10,000A
Specifications
AC Voltage Rating | 250 V |
Amperage Rating | 80 A |
Application | General purpose loads where short circuits are 10,000 amperes or less |
Body Material | FWGE |
Brand Name | Mersen |
Class | Class H |
Connection | Blade |
Connection Material | Brass |
Connection Type | Blade |
Current Rating | 80 A |
Interrupt Rating | 10 kA |
Material | Zinc |
Mounting | Clip |
Series | RF |
Size | Blade |
Size | 5.88 x 1.06 in |
Size | 149.352 x 27 mm |
Special Features | Knurled bushings for ease of disassembly Rugged construction for maximum service life Precision die-cut renewal links renew quickly and give repeatable performance |
Standard | UL listed to standard 248-7 File E2137 CSA certified to standard C22.2 no. 248.7 |
Type | Renewable Fuses |
Voltage Rating | 250 VAC |
Package Dimensions (L x W x H) | 5.88 in x 1.06 in x 1.06 in |
Package Dimensions (L x W x H) | 149.352 mm x 27 mm x 27 mm |
Package Weight (Imperial) | 0.400 lb |
Package Weight (Metric) | 0.181 kg |
GPM-SRR90
Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount
C331156
Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20
LCC5
POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.
Frequently Asked Questions
What is the current rating of the RF80 fuse?
The RF80 fuse has a current rating of 80 amperes.
What type of fuse block is compatible with the RF80?
The RF80 is compatible with Class H renewable fuse blocks.
What applications is the RF80 fuse suitable for?
The RF80 fuse is suitable for general-purpose loads, including motors, transformers, and distribution equipment.
What feature simplifies maintenance of the RF80 fuse?
The RF80 fuse features knurled bushings for ease of disassembly and reassembly during maintenance.
What is the voltage rating of the RF80 fuse?
The RF80 fuse has a voltage rating of 250VAC.
What is the interrupting rating of the RF80 fuse?
The RF80 fuse has an interrupting rating of 10,000 amperes.
Is the RF80 fuse renewable?
Yes, the RF80 is a renewable fuse that uses a die-cut zinc replacement link.
What material is used in the RF80 fuse link?
The RF80 fuse uses a die-cut zinc replacement link.
What standards is the RF80 fuse listed to?
The RF80 fuse is UL listed to standard 248-7 and CSA certified to standard C22.2 no. 248.7.
