Contact for Pricing
Minimum Qty: 3
Multiplier: 3
*Contact for lower quantities*
Overview
- Mersen NH1 Size Fuse-Link
- Rated Voltage: 690VAC
- Rated Current: 125A
- Breaking Capacity: 80 kA
- Type: gG (Full Range Breaking Capacity)
- Features: Live Gripping-Lugs, Striker
- Body Width: 44.60 mm
- Country of Origin: FR
Specifications
AC Voltage Rating | 690 V |
Amperage Rating | 125 A |
Application | gG: general purpose cable and line protection |
Body Material | Ceramic |
Brand Name | Mersen |
Connection | Plain Blades |
Connection Material | Silver-Plated Copper |
Current Rating | 125A |
Interrupt Rating | 80 kA |
Mounting | Clip |
Series | GG |
Size | 5.31 x 1.76 x 2.52 in |
Size | 135 x 44.6 x 64 mm |
Size | NH1 |
Special Features | Dimensions according to DIN 43 620 Parts 1 to 4 Lead free contact blades 0 cadmium |
Standard | VDE 0636 Part 201 IEC 60269-1 and -2 |
Type | IEC NH Fuse-Links |
Type Of Indicators | Striker |
Voltage Rating | 690 VAC |
Voltage Rating | 690VAC |
Package Dimensions (L x W x H) | 5.31 in x 1.76 in x 2.52 in |
Package Dimensions (L x W x H) | 135 mm x 44.6 mm x 64 mm |
Package Weight (Imperial) | 0.765 lb |
Package Weight (Metric) | 0.347 kg |
