Overview
- Class K5 fast-acting ferrule fuse for general-purpose protection
- Rated 600VAC/300VDC, 60A with 50kA AC and 20kA DC interrupting rating
- UL Listed to Standard 248-9 (File E2137) and CSA Certified to Standard C22.2 No. 248.9
- Ideal for lighting, heating, and resistive heating circuits in residential/small commercial applications
- Easy-to-read imprint label for quick identification and replacement
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 60 A |
Application | Feeders Branch circuits Resistive heating Residential and small commercial installations |
Body Material | PolyTube |
Brand Name | Mersen |
Class | Class K5 |
Connection | Ferrule |
Connection Material | Copper |
DC Voltage Rating | 300 V |
Interrupt Rating | 50 kA |
Mounting | Clip |
Size | 5.5 x 1.06 in |
Size | 139.7 x 27 mm |
Special Features | Easy to read imprint label for quick recognition and replacement Low cost for high protection value |
Standard | UL Listed to Standard 248-9 File E2137 CSA Certified to Standard C22.2 No. 248.9 (The Canadian Electrical Code requires these fuses in ratings 15 through 60A to be of the low melting point design use OTN 15-60.) Self-certified for DC per UL248 |
Sub Brand | Amp-Trap® |
Type | Class K5 |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 5.5 in x 1.06 in x 1.06 in |
Package Dimensions (L x W x H) | 139.7 mm x 27 mm x 27 mm |
Package Weight (Imperial) | 0.215 lb |
Package Weight (Metric) | 0.098 kg |
