Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- Fast-acting Amp-Trap® Class K5 fuse for reliable circuit protection
- Rated for 25A, 250VAC, and 250VDC
- High interrupting rating: 50kA at 250VAC, 20kA at 250VDC
- Ideal for general-purpose loads like lighting and heating
- UL Listed to Standard 248-9 and CSA Certified to Standard C22.2 No. 248.9
Specifications
AC Voltage Rating | 250 V |
Amperage Rating | 25 A |
Application | Feeders Branch circuits Resistive heating Residential and small commercial installations |
Body Material | Paper |
Brand Name | Mersen |
Class | Class K5 |
Connection | Ferrule |
Connection Material | Copper |
DC Voltage Rating | 250 V |
Interrupt Rating | 50 kA |
Mounting | Clip |
Size | 2 x 0.56 in |
Size | 50.8 x 14.275 mm |
Special Features | Easy to read imprint label for quick recognition and replacement Low cost for high protection value |
Standard | UL Listed to Standard 248-9 File E2137 CSA Certified to Standard C22.2 No. 248.9 (The Canadian Electrical Code requires these fuses in ratings 15 through 60A to be of the low melting point design use OTN 15-60.) Self-certified for DC per UL248 |
Sub Brand | Amp-Trap® |
Type | Class K5 |
Voltage Rating | 250 VAC |
Package Dimensions (L x W x H) | 2 in x 0.56 in x 0.56 in |
Package Dimensions (L x W x H) | 50.8 mm x 14.275 mm x 14.275 mm |
Package Weight (Imperial) | 0.029 lb |
Package Weight (Metric) | 0.013 kg |
