Overview
- UL Listed & CSA Certified for 600VAC/500VDC operation
- 15A ferrule fuse with 200kA (AC) and 100kA (DC) interrupting ratings
- Low I²t for semiconductor protection (diodes, SCRs, GTOs, SSRs)
- Optimized for high cycling in motor controllers and soft-starters
- Compact design with excellent cycling ability to prevent nuisance openings
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 15 A |
Application | Branch circuits Control panels Electronic motor controllers Phase controllers Drives Soft-starters Solid state relays |
Body Material | GMG |
Brand Name | Mersen |
Class | Class J |
Connection | Ferrule |
Connection Material | Tin-Plated Copper |
DC Voltage Rating | 500 V |
Fuse Class | J |
Interrupt Rating | 200 kA |
Mounting | Clip |
Size | 2.25 x 0.81 in |
Size | 57.15 x 20.65 mm |
Special Features | Optimized over-load capability for withstanding elevated levels of current during electronic motor controller starts Low I2t (low thermal energy) Excellent cycling ability for frequent starts/stops without nuisance opening |
Standard | UL listed to standard 248-8 File E2137 CSA certified to standard C22.2 no. 248.8 DC listed to UL 248 |
Sub Brand | Amp-Trap® |
Type | Class J |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 2.25 in x 0.81 in x 0.81 in |
Package Dimensions (L x W x H) | 57.15 mm x 20.65 mm x 20.65 mm |
Package Weight (Imperial) | 0.089 lb |
Package Weight (Metric) | 0.040 kg |
