Contact for Pricing
Minimum Qty: 3
Multiplier: 3
*Contact for lower quantities*
Overview
- Mersen Protistor® high-speed fuse-link
- Size NH 000, 'aR' rating for semiconductor protection
- 75A rated current, 690VAC operating voltage
- 200 kA rated breaking capacity
- Includes striker L brackets for trip indication
Specifications
AC Voltage Rating | 690 V |
Amperage Rating | 75 A |
Application | Protection of inverters, motor drives, UPS systems and similar 690V or less equipments. |
Brand Name | Mersen |
Case | Ceramic |
Connection | L Brackets |
Connection Type | DIN 80 Blades |
Current Rating | 75 A |
Material | Silver-plated, non-magnetic hardware |
Mounting | Bolted |
Mounting Type | L Brackets |
Mounting Type | Square Body |
Series | Protistor® |
Size | 3.7 x 1.26 x 1.06 in |
Size | 94 x 32 x 27 mm |
Size | NH 000 |
Special Features | aR Class according to IEC 60269-4 and VDE 636-23 Very low I²t for improved semiconductor protection Ultra fast acting Superior cycling capability |
Standard | IEC 60269-4 Compliance UL/CSA Recognized Component AC: UL Guide No. E76491 |
Sub Brand | Protistor® |
Type | Square Body High-Speed Fuse-Links AC Protection |
Type Of Indicators | Striker |
Voltage Rating | 690 VAC |
Voltage Rating | 690 V |
Wattage | 20.5 W |
Package Dimensions (L x W x H) | 3.7 in x 1.26 in x 1.06 in |
Package Dimensions (L x W x H) | 94 mm x 32 mm x 27 mm |
Package Weight (Imperial) | 0.343 lb |
Package Weight (Metric) | 0.156 kg |
