Mersen H1062791 Fuse Holder Modulostar® 600VAC 600VDC Class CC 3-Pole Visual Indicator
Alternate Item Number: CUSCC3I
Documents & Media
Contact for Pricing
Minimum Qty: 4
Multiplier: 4
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 3-pole Class CC fuse holder for 10.3x38.1mm fuse-links (ATDR/ATMR/ATQR compatible)
- Visual blown fuse indicator for immediate fault detection and reduced downtime
- Finger-safe IP20 protection during operation and fuse replacement
- DIN rail mounting with modular multi-pole assembly via pin-tie kits
- Recommended for Mersen ATDR, ATMR, ATQR fuse-links
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 30 A |
Application | All circuits up to 600V for protection of motors, transformers, low voltage distribution, control circuits, drive protection Non-load operation |
Brand Name | Mersen |
DC Voltage Rating | 600 V |
Maximum Operating Temperature | 70 C |
Minimum Operating Temperature | -40 C |
Mounting | DIN rail acc. EN 60715 |
Number of poles | 3 |
Operating Temperature, Maximum | 158 F |
Operating Temperature, Minimum | -40 F |
Size | 2.41 x 2.07 x 3.12;61.1 x 52.5 x 79.3 in;mm |
Special Features | Modular design Compact design for space saving DIN rail mounting Degree of protection: IP20 Finger safe Easy access to the fuse Lockable without accessory Sealable in closed & open position Optional visual blown fuse indicator Multi-pole assembly kit available Plastic material UL94V2 mini Plastic material R22HL2 for railway application Flame retardant materials with glow wire flammability index to 960°C |
Standard | UL listed UL4248 CSA Certified C22.2 RoHS, Reach compliant |
Sub Brand | Modulostar® |
Type | UL/CSA Fuse Holders |
Package Dimensions (L x W x H) | 2.41 in x 2.07 in x 3.12 in |
Package Dimensions (L x W x H) | 61.1 mm x 52.5 mm x 79.3 mm |
Package Weight (Imperial) | 0.309 lb |
Package Weight (Metric) | 0.140 kg |
Frequently Asked Questions
What is the maximum voltage rating?
The fuse holder supports up to 600VAC and 600VDC operation.
How many poles does this model have?
This is a 3-pole fuse holder configuration.
What is the current rating?
The continuous current rating is 30A with SCCR 200kA AC.
What fuse types are compatible with this holder?
The holder is designed for Mersen Class CC fuse-links, including ATDR, ATMR, and ATQR models.
What applications is this suitable for?
It protects motors, transformers, low-voltage distribution, control circuits, and drive systems up to 600V.
Is this holder finger-safe during fuse replacement?
Yes, it meets IEC IP20 finger-safe protection standards, including during fuse changes.
What materials are used in construction?
The holder is made from durable thermoplastic or thermoset materials, with flame-retardant options including UL94V2 and R22HL2 for railway applications.
