Mersen ALS500 - Forklift Truck ALS 125VAC 125VDC 500A Fast-Acting Blade
More images

Mersen ALS500 Forklift Truck ALS 125VAC 125VDC 500A Fast-Acting Blade

Alternate Item Number: ALS500

UPC: 068938791704


Documents & Media
Technical DrawingLine DrawingSpecification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

Mersen forklift truck and battery isolator fuses are specially designed for the heavy duty loads associated with DC battery powered equipment such as forklift trucks, hand trucks, motorized work platforms, and other DC battery operated systems. Rugged construction and stud mounted bolt-in design assure a long life in adverse conditions for these fuses. This expanded line of forklift truck fuses can fulfill virtually all of your heavy duty circuit protection needs up to 125V AC or DC.

    Specifications

    AC Voltage Rating
    125 V
    Amperage Rating
    500 A
    Application
    Forklift trucks Battery hand trucks Motorized work platforms Battery systems
    Body Material
    PolyTube
    Brand Name
    Mersen
    Connection
    Blade
    Connection Material
    Copper
    DC Voltage Rating
    125 V
    Interrupt Rating
    10 kA
    Mounting
    Bolted
    Size
    4.71 x 1.12 in
    Size
    119.634 x 28.448 mm
    Special Features
    All fuses are AC and DC rated Expanded ampere ratings Time-delay and general purpose types
    Standard
    UL recognized components (All Products) File E60314
    Type
    Forklift Truck Fuses
    Voltage Rating
    125 VAC
    Package Dimensions (L x W x H)
    4.71 in x 1.12 in x 1.12 in
    Package Dimensions (L x W x H)
    119.634 mm x 28.448 mm x 28.448 mm
    Package Weight (Imperial)
    0.260 lb
    Package Weight (Metric)
    0.118 kg
    Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount

    GPM-SRR90

    Fuse Block 600VAC 600VDC Class CC 30A 1/4in Quick Connect / Solder 90 angle screw Knob Panel Mount
    Fuse Holder Modulostar® Size 10x38 IEC 690VAC 690VDC 3-Pole IP20

    E1062696

    Fuse Holder Modulostar® Size 10x38 IEC 690VAC 690VDC 3-Pole IP20
    Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20

    C331156

    Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 1-Pole Visual Indicator Microswitch Pressure Plate IP20
    Fuse Block 600VAC 600VDC Class CC 30A 3-Pole Pressure Plate with Reinforced Clip

    30323R

    Fuse Block 600VAC 600VDC Class CC 30A 3-Pole Pressure Plate with Reinforced Clip
    9F61 Size B Clips 1.6in

    9F61BWW460

    9F61 Size B Clips 1.6in
    POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.

    LCC5

    POWR-JAW clamps improve the contact between fuse and clip. The unnecessary heat from poor contact due to the loss of spring force in the clips can cause nuisance fuse opening and premature aging of surrounding components. High temperature phenolic resin knob designed for the most severe environments 7 sizes to provide effective coverage. Simple design makes installation easy.

    Frequently Asked Questions

    What types of DC battery equipment are these fuses designed for?

    These fuses are designed for DC battery powered equipment like forklift trucks, hand trucks, and motorized work platforms.

    What is the maximum voltage rating for ACK, ACL, and ALS fuses?

    The ACK, ACL, and ALS fuses have a maximum voltage rating of 125V AC or DC.

    What is the ampere range for ALS fuses?

    ALS fuses are available in ampere ratings from 100 to 500A.

    What is the interrupting rating for ALS fuses?

    ALS fuses have an interrupting rating of 10kA I.R. AC / DC.

    What is the voltage rating for CNL and CNN fuses?

    CNL fuses are rated for 80V AC/DC, while CNN fuses are rated for 130V AC and 80V DC.

    What is the interrupting rating for CNL fuses?

    CNL fuses have an interrupting rating of 2.5kA I.R. AC / DC.

    What is the interrupting rating for CNN fuses?

    CNN fuses have an interrupting rating of 2.5kA I.R. AC / DC.

    Are these fuses UL recognized components?

    Yes, all products in this line are UL recognized components with File E60314.

    What is the ampere range for ACK fuses?

    ACK fuses are available in ampere ratings from 1 to 400A.

    What is the ampere range for ACL fuses?

    ACL fuses are available in ampere ratings from 30 to 120A.
